Data Sheet

Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 ×
240)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 ×
240)
Image Enhancement
BLC, HLC, 3D DNR, Defog, EIS
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are
adjustable by client software or web browser
Target Cropping
Yes
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm In (with –S model)
Picture Overlay
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format
Network
Network Storage
microSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS, SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering alarm, network disconnected, IP address conflict, HDD
full, HDD error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function
One-key reset, anti-flicker, three streams, heartbeat, mirror. password protection, privacy
mask, watermark, IP address filter
Firmware Version
5.5.80
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 20 channels
User/Host
Up to 32 users. 3 user levels: administrator, operator and user
Client
iVMS-4200, Hik-Connect
Web Browser
IE 8+, Chrome 41.0-44, Mozilla Firefox 30.0-51, Safari 8.0+
Interface
Audio (With –S model)
1 input (line in/mic in, 3.5 mm), 1 output (3.5 mm), mono sound
Communication Interface
1 RJ45 10M/100M Ethernet port,
1 RS-485 interface (with –S model)
Alarm (With –S model)
1 input, 1 output (max. 24 VDC, 1A or 110 VAC, 500 mA)
Video Output (With –S model)
1Vp-p composite output (75 Ω/BNC)
On-board storage
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button
Yes
Audio (With –S Model)
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate
64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32-192 Kbps(MP2L2)
General
Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F), -H: -40 °C to 60 °C (-40 °F to 140 °F)
Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 20%, three-core terminal block
PoE (802.3at, class 3)
Power Consumption and
Current
12 VDC, 1.3 A, max. 15 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.2 A, max. 15 W
Protection Level
IP67
Heater
-H: yes
Material
Metal
