quick start guide hp surestore fc 1Gb/2Gb switch 16B www.hp.
Notice Safety notices © Hewlett-Packard Company, 2001. All rights reserved. Any servicing, adjustment, maintenance, or repair must be performed only by authorized service-trained personnel. Part number: A7340-96002 Edition: E1201 Format conventions Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
CONTENTS Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v 1 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Next Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Setting QuickLoop Mode on Ports . . . . . . . . . . . . . . . . . . . . . . . . . . Setting Up Speed Negotiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configuring Supported Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Switch Status Indicators . . . . . . . . . . . . . . .
Revision History December 2001 First release. Updates For the most current information about the HP Surestore FC 1Gb/2Gb Switch 16B, visit the support Web site located at http://www.hp.com/support/fc16B. For information about product availability, configuration, and connectivity, consult your HP account representative. Related Publications Related product information can be found in the following publications. Those publications with part numbers are provided as printed copies with your product.
Title Part Number Distributed Fabrics User’s Guide, version 3.0 Available only on CD Zoning User’s Guide, version 3.0 Available only on CD MIB Reference Manual, version 3.0 Available only on CD ISL Trunking User’s Guide, version 3.0 Available only on CD Advanced Performance Monitoring User’s Guide, Available only on CD version 3.
1 INSTALLING THE SWITCH Product Description The HP Surestore FC 1Gb/2Gb Switch 16B is a 16-port Fibre Channel gigabit switch that supports link speeds up to 2 Gbps. Each port automatically negotiates to the highest common speed of all devices connected to the port. The ports are compatible with SFPs (small form factor pluggable media), are universal and self-configuring, and are capable of individually becoming an F_Port (fabric enabled), FL_Port (fabric loop enabled), or an E_Port (expansion port).
• The ambient air temperature near the switch must not exceed 40 degrees Celsius. This is particularly important to verify if the switch is installed in a closed or multi-rack assembly. • The volume of air flow available to the switch must be at least 300 cubic feet per minute. The air vents must not be blocked. Follow these safety guidelines for rack-mount installation: • The rack space must be 1U high, 19 inches wide, and 24 inches deep.
• Four rubber mounting feet (used only for setting up the switch as a stand-alone unit) • Two rails and one bag of rail mounting hardware (required if the switch is to be installed in a rack): • hp surestore FC 1Gb/2Gb Switch 16B Quick Start Guide • HP Surestore FC 1Gb/2Gb Switch 16B Documentation CD-ROM Installing the Switch as a Stand-Alone Unit This section provides instructions for setting up the switch as a stand-alone unit on a flat surface.
b. Turn on the power supply (flip the AC switch to “I”) when ready to supply power to the switch. The switch automatically runs POST (power on self-test) each time it is turned on. c. If the FC 16B includes a second power supply, repeat Steps 4a and 4b for the remaining power supply. Note Do not connect the switch to the network until the IP address is correctly set. For instructions on how to set the IP address, see “Configuring and Connecting the Switch” on page 17.
The following items are required to install the switch in a rack: • FC 16B switch • Power cables • #2 Phillips and T25 Torx screwdrivers • Rails and rail mounting hardware: (2) Rear mounting bracket (6) #8-32 x 5/16 Phillips pan-head screw with captive star lock washer (6) #8 Flat washer (6) M5 Torx head screw with captive lock washer (2) Rubber washer (4) M5 U-type Tinnerman clip (HP rack only) (4) #10-32 square Tinnerman nut (Compaq/Rittal rack only) (4) #10-32 x 5/8 Phillips pan-head screw with atta
For proper airflow, the SFP media side of the FC 16B faces the rear of the rack. This mounting allows air to enter from the front of the rack and to exhaust at the rear of the rack, similar to other rack-mounted equipment. This prevents switch overheating which may cause it to fail CAUTION To install the switch in a rack: 1. Check contents of the shipping carton to verify all the required parts and hardware are available. 2. Choose a mounting location in the rack for the switch. 3.
– For a Compaq/Rittal rack, assemble each of the two brackets with (2) spacers, (2) M5 flat washers, and (1) M5 Torx head screw with captive lock washers as shown in Figure 3. For the Compaq/Rittal rack, the alignment pins will be resting on the top surfaces of the spacers. Note Figure 3. Installing the Rear Rail-Tray Brackets (Compaq/Rittal Rack) 4.
Figure 4. Installing the Tinnerman Clips (HP Rack) – For a Compaq/Rittal rack, install (2) #10-32 square Tinnerman nuts for each of the front columns of the rack in the top and bottom positions of the three-hole EIA pattern. Also install (1) spacer in the center position for each column on the front of the rack. See Figure 5. Figure 5.
5. Assemble the outer rails by completing the following steps: a. As an aid in assembly, two rubber washers have been included to help keep the rear slotted portion of the outer rail flush against the rear rail-tray brackets. Install them as shown in Figure 6. Figure 6. Installing the Rubber Washers b. Insert the alignment pins attached to the outer rail front flange into the center opening in the rack. For the Compaq/Rittal rack, the alignment pins will be resting on the top surfaces of the spacers.
Figure 7. Assembling the Outer Rails (HP Rack) – For a Compaq/Rittal rack, install one #10-32 x 5/8 Phillips pan-head screw in the upper hole location of the right rail. Then, install one #10-32 x 5/8 Phillips pan-head screw in the lower location of the left rail. 6. Assemble the two inner rails (one on each side) to the switch using (6) #8-32 x 5/16 Phillips pan-head screws, and #8 flat washer as shown in Figure 8. Figure 8.
Do not use any other screws other than the six that are provided. Use of any longer lengths can cause damage to internal components of the switch. Before tightening screws, make sure that the rails are centered to the overall height of the switch. CAUTION 7. Insert the switch with the attached inner rails into the outer rails. – For an HP rack, assemble (2) remaining M5 Torx screws to complete the installation. See Figure 9. Figure 9.
b. Turn on the power supply (flip the AC switch to “I”) when ready to supply power to the switch. The switch automatically runs POST (power on self-test) each time it is turned on. c. If the FC 16B includes a second power supply, repeat Steps 8a and 8b for the remaining power supply. Note Do not connect the switch to the network until the IP address is correctly set. For instructions on how to set the IP address, see “Configuring and Connecting the Switch” on page 17.
2 SETUP System Components The HP Surestore FC 1Gb/2Gb Switch 16B consists of the following components: • A 1U chassis, designed to be mounted in a 19-inch rack, with forced-air cooling that flows from the power supply side of the switch to the SFP media side. • 16 optical ports, compatible with SFPs (small form factor pluggable media). • One RS-232 serial port (DB9 connector) on the SFP media side. • One IEEE compliant RJ-45 connector on the SFP media side for use with 10/100 Mbps Ethernet or in-band.
– One LED in the center of the power supply side to indicate the overall switch status. • Two universal input and redundant power supplies with AC switches and built-in fans. The power supplies plug into internal blind-mate connectors when installed in the chassis. • Two fan trays, each containing two fans. Air is pulled in through the rear intake and pushed out through the vents on the SFP media side. The fans provide adequate cooling for the maximum switch power rating of 102 Watts.
The ports on the SFP media side of the FC 16B are color-coded in groups with four purple ports alternating with four unmarked ports to indicate which ports can be used in the same ISL Trunking group. Note ISL Trunking (an optionally licensed feature) is a Fabric OS feature that enables distribution of traffic over the combined bandwidth of up to four ISLs between two directly adjacent switches, while preserving in-order delivery. For information about ISL Trunking, refer to the ISL Trunking User’s Guide.
To turn the FC 16B on, connect one or both power supplies to a power source, then flip the AC power switch to the “I” position. To turn the switch off, turn off both power supplies (if both are installed) by flipping each AC power switch to the “O” position. Note Removing all power from the switch triggers a system reset. When power is restored, all devices are returned to the last saved state and the switch runs POST. Fabric Operating System Included with the switch is the Fabric OS.
GBIC optic modules. LC to SC cables or adapters are required to connect the cables together. To connect an SC cable to the FC 16B, use the HP C7540A - 2M LC male SC male cable adapter. Connect inter switch links (ISLs) between two FC 16B switches using an LC to LC cable. Table 1.
• Workstation that has a terminal emulator application (such as HyperTerminal) • Serial cable provided with the switch, for connecting the switch to the workstation • An unused IP address • Ethernet cable for connecting the switch to the workstation or to a network containing the workstation • SFPs and FC cables, as required to connect the switch to the fabric To configure the FC 16B and connect it to a fabric: 1.
– In a UNIX environment, enter the following string at the prompt: tip /dev/ttyb -9600 f. From the terminal emulator application, log on to the switch with administrative privileges through the serial connection. The default administrative logon is admin and the default password is password. Do not change the default password unless local administration policy requires it. CAUTION g. Enter the following at the prompt: ipAddrSet h.
Note The serial port is intended only for use during the initial setting of the IP address and for service purposes. Using the serial port during normal switch operation or for regular maintenance is not recommended. 2. Record the IP address for future reference. 3. Connect the switch to the workstation computer by Ethernet cable (can be a direct connection or through a network) by completing the following steps: a. Remove the shipping plug from the Ethernet port. b.
a. Disable the switch by entering the following: switchDisable b. Enter the following: configure c. Enter the following at the Fabric parameters prompt: y d. Enter a unique domain ID: Domain: (1..239) [1] 3 e. Complete the remaining prompts (or press CTRL+D to accept the remaining settings without completing all the prompts). f. Re-enable the switch by entering the following: switchEnable 6. Optional: Specify any custom status policies for the fabric by completing the following steps: a.
c. Connect the cables to the SFPs as appropriate to the fabric topology. Position each cable so that the key (the ridge on one side of the cable connector) is aligned with the slot in the SFP. Then, insert the cable into the SFP until it is firmly seated and the latching mechanism clicks. The cable is keyed so that it can only be inserted correctly into the SFP. If the cable does not slide in easily, ensure it is correctly oriented. Note 8.
1. Verify that the RSHD service (on a UNIX machine) or the FTP service (on a Windows machine) is running on the host workstation. 2. Login to the switch as the admin user. 3.
system configuration file, and password is the password for the user ID specified. Note The password operand is only required if you are using FTP. 5. Reboot the switch by entering the following command: fastBoot Next Steps Specific tasks remain to be completed before the switch is fully operational and manageable in your network with your equipment. These tasks and the associated tools are described in the remaining documents shipped with the product on the documentation CD-ROM.
Configuring Supported Devices HP Surestore Director FC-64 Switch The FC 16B switch can be used with the HP Surestore Director FC-64 switch. Specific configurations must be set on both devices to make this work. On the FC 16B, logon to the switch with administrative privileges and enter the following telnet commands: 1. switchDisable 2. interopMode 1 3.
HP Surestore VA 7400 The FC 16B also can support a 2Gb connection to an HP Surestore Virtual Array 7400. Set the port speed to 2Gb using the telnet command portCfgSpeed. Use the Virtual Front Panel (VFP) on the VA 7400 and configure the device as follows: 1. Change the controller port data rate to 2 Gbits/s a. To change the port data rate to 2 gigabits/second for controller 1, enter: vfpmgr -S 2 -c 1 When prompted to reset, enter no. b.
3 DIAGNOSTICS Switch Status Indicators System activity and status can be determined through the activity of the LEDs on the switch. The LEDs may flash yellow during diagnostic tests; green, yellow, or orange during POST. This is normal and does not indicate a problem unless the LEDS do not return to a normal pattern after POST or the other diagnostic tests are complete.
• One switch status LED in the center of the power supply side to indicate whether the switch is on and has successfully booted, and whether any of the ports are faulty. LEDs on the SFP Media Side Figure 12 shows the SFP media side of the FC 16B with the LEDs identified. Switch Power LED Ethernet Port Serial Port Optical Port (16x) Port Status LED (16x) Port Speed LED (16x) Figure 12. The SFP Media Side of the FC 16B The following table describes the LEDs above each port on the left.
Color of LED Status of Hardware Fast-flashing green (on 1/4 second; off 1/4 second) The port is in internal loopback No action required. (diagnostic). Flickering green Port is online, with traffic flowing through port. Flashing or steady POST is running. yellow Recommended Action No action required. No action required. Steady orange Port is receiving light or signal No action required. carrier, but is not yet online.
The following table describes the LEDs below the serial port. These LEDs indicate the switch power. Color of LED Status of Hardware Recommended Action No light Either the switch is off, or boot Verify that the switch is not complete, or boot has is on and boot has had failed. time to complete. If there is still no light, contact HP support. Steady green Switch is on and boot has successfully completed. No action required. Slow-flashing green Diagnostic failure on one or more ports.
The following table describes the LEDs on each power supply. These LEDs indicate the status of the related power supply. Color of LED Status of Hardware Recommended Action No light Power supply is not providing power. Verify power supply is on and power cable is connected to a valid power source. Steady green Power supply is providing power. No action required. The following table describes the LED in the center of the power supply side. This LED indicates the status of the switch.
Maintenance and Diagnostic Tests The FC 16B does not require any regular physical maintenance, and is designed to minimize the chance of failure, including diagnostic tests and field-replaceable units. Diagnostic tests are provided to help troubleshoot the hardware and the firmware. The diagnostic tests provided on the switch include tests of internal connections and circuitry, fixed media, and any SFP modules and fiber optic cables in use.
Test Command Description Content camTest Addressable Memory (CAM) Test Verifies CAM functionality. Run offline. Port Loopback Test portLoopbackTest Checks all switch main board hardware. Frames transmitted are looped back and received. Run offline. Cross Port Test crossPortTest Checks all switch paths. Frames transmitted by port M are looped back via external cable and received at port N. Run offline or online. Spin Silk Test spinSilk Checks all switch paths at the maximum speed of 1 Gbps.
Error Messages To analyze error messages, access the error message log via a Telnet session using the errDump command. Note any messages before removing power from the switch; error messages are stored in RAM and are lost when power is removed. See the Fabric OS Reference Manual for a detailed description of each message. Getting Support Service and Support There are no customer serviceable parts in the FC 16B. For the most current technical support information for the FC 16B, visit the HP Web site at www.
4 SPECIFICATIONS General The following table lists the general specifications for the HP Surestore FC 1Gb/2Gb Switch 16B. Specification Description Fabric initialization Complies with FC-SW 5.0 IP over Fibre Channel (FC-IP) Complies with FC-IP 2.
Specification Description Modes of operation Fibre Channel Class 2 and Class 3 Aggregate switch I/O bandwidth 64 Gbps if all 16 ports running at 2 Gbps, full duplex Frame buffers 27 buffers per E_Port and 16 buffers per F_Port at 2112 bytes per frame Port to port latency Less than 2 microseconds with no contention (destination port is free) Data transmission range Up to 500 m (1,625 ft.) for short-wavelength optical link Up to 10 km (32,820 ft.
Condition Acceptable Range Vibration (non-operating) 10 G, 0-5 kHz at 1.0 octave/minute Dimensions The following table lists the dimensions of the FC 16B. Dimension Value Height 1U Depth 24 inches (61.0 cm) Width 17 inches (43.2 cm) Weight (with both power supplies installed) 28.5 lbs (12.9 kg) Power Supply The following table lists the power supply specifications.
38 Quick Start Guide
PRODUCT REGULATORY INFORMATION FCC EMC Statement (USA) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Germany Noise Declaration Schalldruckpegel Lp = 46.
Laser Safety A. Certification and Classification Information When equipped with native Fibre Channel adapters, this product contains a laser internal to the small form factor pluggable (SFP) transceiver modules. In the USA, the SFP module is certified as a Class 1 Laser product, conforming to the requirements contained in Department Of Health and Human Services (DHHS) regulation 21 CFR, Subchapter J. The certification is indicated by a label on the metal SFP housing.
Declaration of Conformity DECLARATION OF CONFORMITY according to ISO/IEC Guide 22 and EN 45014 Manufacturer's Name: Hewlett-Packard Company Network Storage Solutions Organization Manufacturer's Address: 8000 Foothills Blvd.
