HP StorageWorks

4Gb SAN Director

Port Blade

installation instructions

First edition (November 2006)

Product names mentioned herein may be trademarks of their

respective companies as reflected by an associated footnote.

The information in this document is subject to change without

notice.

Printed in the US

www.hp.com

7990-90003*

Overview

Read these instructions to install the following optional 4Gb SAN

Director Port Blades:

• HP StorageWorks 16 Port 4Gb Blade (FC4–16) ,

Part Number A7990A, installs in the HP StorageWorks

SAN Director 2/128 or HP StorageWorks 4/256 SAN Director

models

only

• HP StorageWorks 32 Port 4Gb Blade (FC4–32),

Part Number A79 91A, installs in the HP StorageWorks

4/256 SAN Director model

only

• HP StorageWorks 4/48 SAN Director B lade (FC4–48),

Part Number AG561A, installs in the the HP StorageWorks 4/256

SAN Director model

only

NOTE:

For simplicity, the port blades are referred to as FC4–16,

FC4–32 and FC4–48 throughout this document.

Refer to the HP StorageWorks SAN Director installation guide for a

complete list of 4Gb SAN Director Port Blade technical specifications.

Intended audience

These installation instructions are intended for use by system technicians

who are experienced with:

• Setting up dev ices in a SAN

• HP StorageWorks Fibre Channel Directors

Relate

ddocumentation

For the

latest information, documentation, and firmware releases, please

visit t

he following HP StorageWorks web site:

ttp://www.hp.com/country/us/eng/prodserv/storage.html

Compatibilit y

Refer to Table 1 to determine which SAN Director models are

compatible with your specific 4Gb SAN Director P ort Blade.

IMPORTANT:

Install 4Gb Port Blades in the SAN Director models listed only.

Table 1 4Gb SAN Direc tor Port Bla d e compatibility

4/16 SAN

Director Por t

Blade (FC4-16)

4/32 SAN

Director

Port Blade

(FC4–32)

4/48 SAN

Director

Port Blade

(FC4–48)

SAN Director

2/128

Compatible

Not

compatible

Not

compatible

4/256 SAN

Director

Compatible Compatible Compatible

NOTE:

Installation procedures for the B-Seri es Multi-protocol Router

Blade are not included in this document. Please re fer to

the

HP StorageWorks B-Series Multi-protocol Router Blade

installation guide

available via the link provided above in

Summary of content (4 pages)
