103
inband-llb-up:0 times, inband-llb-down:0 times.
fdl-ansi-llb-up:0 times, fdl-ansi-llb-down:0 times.
fdl-ansi-plb-up:0 times, fdl-ansi-plb-down:0 times.
BERT state:(stopped, not completed)
Test pattern: 2^15, Status: Not Sync, Sync Detected: 0
Time: 0 minute(s), Time past: 0 minute(s)
Bit Errors (since test started): 0 bits
Bits Received (since test started): 0 Kbits
Bit Errors (since latest sync): 0 bits
Bits Received (since latest sync): 0 Kbits
Historical Statistics:
Last clearing of counters: Never
Data in current interval (285 seconds elapsed):
0 Line Code Violations, 0 Path Code Violations
0 Ais Alarm Secs, 286 Los Alarm Secs
7 Slip Secs, 286 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 286 Unavail Secs
Data in Interval 1:
0 Line Code Violations, 0 Path Code Violations
0 Ais Alarm Secs, 901 Los Alarm Secs
22 Slip Secs, 901 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 901 Unavail Secs
Data in Interval 2:
0 Line Code Violations, 0 Path Code Violations
0 Ais Alarm Secs, 900 Los Alarm Secs
23 Slip Secs, 900 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 900 Unavail Secs
Total Data (last 2 15 minute intervals):
0 Line Code Violations, 0 Path Code Violations
0 Ais Alarm Secs, 2087 Los Alarm Secs
52 Slip Secs, 2087 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 2087 Unavail Secs
Table 18 Command output
Field Descri
p
tion
T1 2/0/0 current state Physical state of the interface: up or down.
Description Description about the T1 interface.
Basic Configuration Basic configurations of the interface.
Work mode
Operating mode of the T1 interface, T1 framed in this
example.
Cable type
Cable type of the T1 interface, 100 ohm balanced in
this example.
Frame-format
Frame format configured on the T1 interface: ESF or
SF.
fdl FDL format: ANSI, ATT, or none.
Line code Line code: AMI or B8ZS.
