104
Field Descri
p
tion
Source clock
Source clock used by the interface: master for the
internal clock or slave for the line clock.
Data-coding Normal or inverted.
Idle code 0x7E or 0xFF.
Itf type Type of interframe filling tag: 0x7E or 0xFF.
Itf number Number of interframe filling tags.
Loop back
Loopback setting on the interface: local, payload,
remote, or not set.
Alarm State Alarm state.
Receiver alarm state Type of received alarm: none, LOS, LOF, RAI, or AIS.
Transmitter is sending remote alarm. Type of transmitted alarm: RAI, or none.
Pulse density violation detected
The detected pulse density is incompliant with the
specification.
SendLoopCode History:
inband-llb-up:0 times, inband-llb-down:0
times.
fdl-ansi-llb-up:0 times, fdl-ansi-llb-down:0 times.
fdl-ansi-plb-up:0 times, fdl-ansi-plb-down:0 times
History of loopback code sending to the peer end,
including the number of transmissions for each type of
code, and the type of the last sent code. (For more
information, see the sendloopcode command
.)
BERT state:(stopped, not completed)
BERT state: completed, stopped (not completed), or
running.
Test pattern: 2^15, Status: Not Sync, Sync Detected:
0
Test pattern in use (2^20 or 2^15), 2^15 in this
example; synchronization state, and the number of
detected synchronizations.
Time: 0 minute(s), Time past: 0 minute(s) Duration of the BERT test and time that has elapsed.
Bit Errors (since test started)
Number of bit errors received since start of the BERT
test.
Bits Received (since test started) Number of bits received since start of the BERT test.
Bit Errors (since latest sync)
Number of bit errors received since last
synchronization.
Bits Received (since latest sync) Number of bits received since last synchronization.
Historical Statistics: Historical statistics.
Last clearing of counters Counter clearing records.
Data in current interval (285 seconds elapsed):
0 Line Code Violations, 0 Path Code Violations
0 Ais Alarm Secs, 286 Los Alarm Secs
7 Slip Secs, 286 Fr Loss Secs, 0 Line Err Secs, 0
Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err
Secs, 286 Unavail Secs
Statistics in the current interval. The statistical items,
such as AIS alarm, LOS signal, and LFA, are provided
according to the T1 specifications for the physical
layer.
For more information, see ANSI T1.403 and AT&T TR
54016.
