114
Basic Configuration:
Work mode is E1 framed, Cable type is 75 Ohm unbalanced.
Frame-format is no-crc4.
Line code is hdb3, Source clock is slave.
Idle code is 7e, Itf type is 7e, Itf number is 4.
Loopback is not set.
Alarm State:
Receiver alarm state is None.
Transmitter is sending remote alarm.
Historical Statistics:
Last clearing of counters: Never
Data in current interval (19349 seconds elapsed):
129 Loss Frame Alignment Secs, 0 Framing Error Secs,
0 CRC Error Secs, 0 Alarm Indication Secs, 129 Loss-of-signals Secs,
0 Code Violations Secs, 0 Slip Secs, 0 E-Bit error Secs.
Table 19 Command output
Field Descri
p
tion
Cable type Cable type of the interface(75-ohm unbalanced/120-ohm balanced).
Frame-format Framing format (CRC4/no-CRC4).
Line Code Line code format: AMI or HDB3.
Source Clock Source clock: master for internal clock and slave for line clock.
Idle code Idle code (7e/ff).
Itf type Interframe filling tag (7e/ff)
Itf number Number of Interframe filling tags.
Loopback Whether loopback is configured on the interface.
Alarm State: Receiver
alarm state is None
Alarm status.
Last clearing of counters Last time when the interface statistics is cleared.
Data in current interval
(19349 seconds elapsed):
129 Loss Frame
Alignment Secs, 0 Framing
Error Secs,
0 CRC Error Secs, 0
Alarm Indication Secs,
129 Loss-of-signals Secs,
0 Code Violations Secs,
0 Slip Secs, 0 E-Bit error
Secs.
Time duration that each error lasts within the interval. The errors include frame
misalignment, frame errors, alarms, loss of signals, code violation, and frame
slipping.
error-diffusion restraint config
Use error-diffusion restraint config to set the three parameters in error packets diffusion restraint.
