127
Field Descri
p
tion
Frame-format Frame format configured on the interface: ESF or SF.
fdl FDL format: ANSI, ATT, or none.
Line code AMI or B8ZS.
Source Clock
Source clock used by the interface: master for the
internal clock or slave for the line clock.
Data-coding Normal or inverted.
Idle code Idle code, 0x7E or 0xFF.
Itf type Type of inter-frame filling tags: 0x7E or 0xFF.
Itf number Number of inter-frame filling tags.
Loop back
Loopback setting on the interface: local, payload,
remote, or not set.
Alarm State Alarm state.
Receiver alarm state Type of received alarm: none, LOS, LOF, RAI, or AIS.
Transmitter is sending remote alarm. Type of transmitted alarm: RAI, or none.
Pulse density violation detected
The detected pulse density is incompliant with the
specification.
SendLoopCode History:
inband-llb-up:0 times, inband-llb-down:0
times.
fdl-ansi-llb-up:0 times, fdl-ansi-llb-down:0 times.
fdl-ansi-plb-up:0 times, fdl-ansi-plb-down:0 times
History of loopback code sending to the far-end,
including the number of transmissions for each type of
code, and the type of the last sent code. (For more
information, see "ft1 sendloopcode.")
BERT state:(stopped, not completed)
BERT state: completed, stopped (administratively
stopped), or running.
Test pattern: 2^15, Status: Not Sync, Sync Detected:
0
Test pattern in use, 2^15 in this sample output;
synchronization state, and the number of detected
synchronizations.
Time: 0 minute(s), Time past: 0 minute(s) Duration of the BERT test and time that has elapsed.
Bit Errors (since test started)
Number of bit errors received since start of the BERT
test.
Bits Received (since test started) Number of bits received since start of the BERT test.
Bit Errors (since latest sync)
Number of bit errors received since last
synchronization.
Bits Received (since latest sync) Number of bits received since last synchronization.
Historical Statistics: Historical statistics.
Last clearing of counters: Never Counter clearing records.
