R3303-HP HSR6800 Routers Interface Command Reference
Table Of Contents
- Title Page
- Contents
- Ethernet interface configuration commands
- General Ethernet interface and subinterface configuration commands
- bandwidth
- combo enable
- description
- display counters
- display counters rate
- display interface
- display packet-drop interface
- display packet-drop summary
- duplex
- flag sdh
- flow-interval
- interface
- ip fast-forwarding
- link-delay
- loopback
- port link-mode
- port link-mode interface-list
- port-mode
- reset counters interface
- reset packet-drop interface
- shutdown
- speed
- sub-interface rate-statistic
- Layer 2 Ethernet interface and subinterface configuration commands
- broadcast-suppression
- display loopback-detection
- display port-group manual
- display storm-constrain
- flow-interval
- group-member
- jumboframe enable
- loopback-detection action
- loopback-detection control enable
- loopback-detection enable
- loopback-detection interval-time
- loopback-detection multi-port-mode enable
- loopback-detection per-vlan enable
- mdi
- multicast-suppression
- port-group manual
- speed auto
- storm-constrain
- storm-constrain control
- storm-constrain enable log
- storm-constrain enable trap
- storm-constrain interval
- unicast-suppression
- virtual-cable-test
- Layer 3 Ethernet interface and subinterface configuration commands
- General Ethernet interface and subinterface configuration commands
- ATM interface configuration commands
- WAN interface configuration commands
- Common WAN interface configuration commands
- Serial interface configuration commands
- Basic CE1 interface configuration commands
- Alarm
- cable (CE1 interface)
- channel-set (CE1 interface)
- clock (CE1 interface)
- clock-change auto
- code (CE1 interface)
- controller e1
- crc
- data-coding (CE1 interface)
- detect-ais
- display controller e1
- error-diffusion restraint config
- error-diffusion restraint enable
- frame-format (CE1 interface)
- idlecode (CE1 interface)
- itf (CE1 interface)
- loopback (CE1 interface)
- reset counters controller e1
- using (CE1 interface)
- Basic CT1 interface configuration commands
- alarm (CT1 interface)
- alarm-threshold
- bert (CT1 interface)
- cable (CT1 interface)
- channel-set (CT1 interface)
- clock (CT1 interface)
- code (CT1 interface)
- controller t1
- crc
- data-coding (CT1 interface)
- display controller t1
- error-diffusion restraint config
- error-diffusion restraint enable
- fdl
- frame-format (CT1 interface)
- idlecode (CT1 interface)
- itf (CT1 interface)
- loopback (CT1 interface)
- reset counters controller t1
- sendloopcode
- E1-F interface configuration commands
- T1-F interface configuration commands
- Basic CE3 interface configuration commands
- Basic CT3 interface configuration commands
- alarm (CT3 interface)
- bert (CT3 interface)
- cable (CT3 interface)
- clock (CT3 interface)
- controller t3
- crc
- display controller t3
- feac
- frame-format (CT3 interface)
- ft3
- link-delay
- loopback (CT3 interface)
- mdl (CT3 interface)
- reset counters controller t3
- t1 alarm
- t1 bert
- t1 channel-set
- t1 sendloopcode
- t1 set clock
- t1 set fdl
- t1 set frame-format
- t1 set loopback
- t1 show
- t1 shutdown
- t1 unframed
- using (CT3 interface)
- POS interface configuration commands
- CPOS interface configuration commands
- bandwidth
- clock
- controller cpos
- description
- display controller cpos
- display controller cpos e1
- display controller cpos e3
- display controller cpos t1
- display controller cpos t3
- e1 channel-set
- e1 set clock
- e1 set flag
- e1 set frame-format
- e1 set loopback
- e1 shutdown
- e1 unframed
- e3 set clock
- e3 set loopback
- e3 set national-bit
- e3 shutdown
- fe3
- flag
- flag vc-3
- flag vc-4
- frame-format
- ft3
- link-delay
- loopback
- multiplex mode
- ppp mp soft-binding
- reset counters controller cpos
- shutdown
- t1 channel-set
- t1 set clock
- t1 set flag
- t1 set frame-format
- t1 set loopback
- t1 shutdown
- t1 unframed
- t3 set alarm
- t3 set bert pattern
- t3 set clock
- t3 set feac
- t3 set frame-format
- t3 set loopback
- t3 set mdl
- threshold
- using e3
- using t3
- E-CPOS interace configuration commands
- Loopback and null interface configuration commands
- Support and other resources
- Index
6
Field Description
Overflow: more than 14
decimal digits.
The command displays Overflow if any of the following applies:
• The data length of an error statistic is greater than 7 decimal digits.
• The data length of a non-error statistic is greater than 14 decimal digits.
--: not supported. The statistical item is not supported.
Related commands
flow-interval
display interface
Use display interface to display Ethernet interface information.
Syntax
display interface [ interface-type ] [ brief [ down ] ] [ | { begin | exclude | include } regular-expression ]
display interface interface-type { interface-number | interface-number.subnumber } [ brief [ description ] ]
[ | { begin | exclude | include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
Parameters
interface-type: Specifies an interface type.
interface-number: Specifies an interface number.
interface-number.subnumber: Specifies a subinterface number, where interface-number is an interface
number, and subnumber is the number of a subinterface created under the interface. The subnumber
argument is in the range of 1 to 4094.
brief: Displays brief interface information. If you do not specify this keyword, the command displays
detailed interface information.
description: Displays the full description of the specified interface. If the keyword is not specified, the
command displays at most the first 27 characters of the interface description. If the keyword is specified,
the command displays all characters of the interface description.
down: Displays information about interfaces in the down state and the causes. If you do not specify this
keyword, this command displays information about interfaces in all states.
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Fundamentals Configuration Guide.
begin: Displays the first line that matches the specified regular expression and all lines that follow.
exclude: Displays all lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
