8
Table 3 Command output
Field Description
GigabitEthernet4/0/1 current
state
State of the Ethernet interface:
• DOWN ( Administratively )—The Ethernet interface was shut down with
the shutdown command. The interface is administratively down.
• DOWN ( Link-Aggregation interface down )—The Ethernet interface is
physically down because the aggregate interface corresponding to the
aggregation group to which the Ethernet interface belongs was shut
down with the shutdown command.
• DOWN—The Ethernet interface is administratively up but physically
down (possibly because no physical link is present or the link has failed).
• UP—The Ethernet interface is both administratively and physically up.
Line protocol current state
Link layer state of the interface:
• DOWN—The interface is physically down.
• UP—The interface is physically up.
Internet protocol processing
Disabled indicates that IP packets cannot be processed.
For an interface configured with an IP address, this field changes to Internet
Address is.
Media type is Physical medium, twisted pair or optical fiber.
loopback not set
The loopback testing function is disabled.
For an interface configured with the loopback external or loopback internal
command, this field changes to loopback is set.
promiscuous mode not set The interface is operating in non-promiscuous mode.
Output queue (Urgent queue:
Size/Length/Discards)
Output queue (current message number in the urgent queue, maximum
number of messages allowed in the urgent queue, and number of discarded
messages).
Output queue (Protocol queue:
Size/Length/Discards)
Output queue (current message number in the protocol queue, maximum
number of messages allowed in the protocol queue, and number of
discarded messages).
Output queue (FIFO queuing:
Size/Length/Discards)
Output queue (current message number in the FIFO queue, maximum
number of messages allowed in the FIFO queue, and number of discarded
messages).
Last clearing of counters
Time when the reset counters interface command was last used to clear the
interface statistics. If the command was never used since the device was
started, this field displays Never.
Last 300 seconds input rate
Average input rate over the last 300 seconds in Bps, bps, and pps.
The statistics polling interval, 300 seconds in this example, can be
configured by using the flow-interval command.
Last 300 seconds output rate
Average output rate over the last 300 seconds in Bps, bps, and pps.
The statistics polling interval, 300 seconds in this example, can be
configured by using the flow-interval command.
Input Input packets.
Output Output packets.
