Periodical detection is enabled, no code received now.
BERT state:(stopped, not completed)
Test pattern: 2^7, Status: Not Sync, Sync Detected: 0
Time: 0 minute(s), Time past: 0 minute(s)
Bit errors (since test started): 0 bits
Bits received (since test started): 0 Mbits
Bit errors (since latest sync): 0 bits
Bits received (since latest sync): 0 Mbits
Historical Statistics:
Last clearing of counters: 14:39:02 UTC Sat 06/25/2005
Data in current interval (22 seconds elapsed):
0 Line Code Violations, 0 Far End Block Error
0 C-Bit Coding Violation, 0 P-bit Coding Violation
0 Framing Bit Err, 0 Severely Err Framing Secs
0 C-bit Err Secs, 0 C-bit Severely Err Secs
0 P-bit Err Secs, 0 P-bit Severely Err Secs
0 Unavailable Secs, 0 Line Err Secs
T3 2/0/0 CT1 1 is up
Frame-format ESF, clock slave, loopback not set
FDL Performance Report is disabled
Transmitter is sending none
Receiver alarm state is none
Line loop back deactivate code using inband signal last sent
BERT state:(stopped, not completed)
Test pattern: 2^11, Status: Not Sync, Sync Detected: 0
Time: 0 minute(s), Time past: 0 minute(s)
Bit errors (since test started): 0 bits
Bits received (since test started): 0 Kbits
Bit errors (since latest sync): 0 bits
Bits received (since latest sync): 0 Kbits
Table 21 Command output
Field Descri
p
tion
T3 2/0/0 current state Physical state of the interface: up or down.
Description : T3 2/0/0 Interface Description about the interface.
Link delay is 8(sec) Physical state change suppression interval of the interface.
Basic Configuration Basic configurations of the interface.
Work mode Operating mode of the interface, CT3 or T3.
cable length Cable length supported by the interface.
Frame-format Frame format: C-bit parity or M23.
line code In this output sample, line code is B3ZS.
Source clock
Clock source used by the interface: master for the internal clock or
slave for the line clock.
loopback Loopback setting on the interface: local, remote, payload, or not set.
