10
Field Description
Last clearing of counters
Time when the reset counters interface command was last used to clear
statistics on the subinterface.
If the command was never used since the device was started, this field
displays Never.
Input Input packet statistics.
Output Output packet statistics.
# Display detailed information about Layer 2 interface GigabitEthernet 4/0/1.
<Sysname> display interface gigabitethernet 4/0/1
GigabitEthernet4/0/1 current state: UP
IP Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 0000-000f-0007
Description: GigabitEthernet4/0/1 Interface
Loopback is not set
Media type is twisted pair
port hardware type is 1000_BASE_T
100Mbps-speed mode, half-duplex mode
Link speed type is autonegotiation, link duplex type is autonegotiation
Flow-control is not enabled
The Maximum Frame Length is 1536
Broadcast MAX-ratio: 100%
Unicast MAX-ratio: 100%
Multicast MAX-ratio: 100%
Allow jumbo frame to pass
PVID: 999
Mdi type: auto
Port link-type: access
Tagged VLAN ID : none
Untagged VLAN ID : 999
Port priority: 0
Last clearing of counters: Never
Peak value of input: 0 bytes/sec, at 2003-09-16 16:25:33
Peak value of output: 0 bytes/sec, at 2003-09-16 16:25:33
Last 300 seconds input: 0 packets/sec 74 bytes/sec 0%
Last 300 seconds output: 0 packets/sec 12 bytes/sec 0%
Input (total): 21322 packets, 1748554 bytes
- unicasts, - broadcasts, - multicasts, - pauses
Input (normal): 21322 packets, - bytes
1268 unicasts, 7560 broadcasts, 12494 multicasts, 0 pauses
Input: 0 input errors, 0 runts, 0 giants, - throttles
0 CRC, - frame, - overruns, - aborts
- ignored, - parity errors
Output (total): 1502 packets, 138924 bytes
- unicasts, 2 broadcasts, 406 multicasts, 0 pauses
Output (normal): - packets, - bytes
1094 unicasts, - broadcasts, - multicasts, - pauses
Output: 3 output errors, - underruns, - buffer failures
