11
- aborts, 1 deferred, 2 collisions, 0 late collisions
- lost carrier, - no carrier
Table 5 Command output
Field Description
GigabitEthernet4/0/1 current state
Physical state of the Ethernet interface. For more information, see Table
6.
IP Packet Frame Type Ethernet framing format on the interface.
Loopback Loopback testing status of the interface.
100Mbps-speed mode
The interface is operating at 100 Mbps.
This field displays Unknown-speed mode when the interface is
disconnected from the peer that it will automatically negotiate a port
speed with.
half-duplex mode
The interface is operating in half-duplex mode.
This field displays link duplex type is force link when the duplex mode
of the interface is fixed and not configurable.
Link speed type is autonegotiation The interface will negotiate a speed with its peer.
link duplex type is autonegotiation The interface will negotiate a duplex mode with its peer.
The Maximum Frame Length Maximum Ethernet frame length allowed on the interface.
Broadcast MAX-ratio
Broadcast suppression threshold as a percentage of the maximum
interface rate. When the threshold is exceeded, the interface drops
broadcast packets.
Unicast MAX-ratio
Unknown unicast suppression threshold as a percentage of the
maximum interface rate. When the threshold is exceeded, the
interface drops unknown unicast packets.
Multicast MAX-ratio
Multicast suppression threshold as a percentage of the maximum
interface rate. When the threshold is exceeded, the interface drops
multicast packets.
Allow jumbo frame to pass Jumbo frames are allowed to pass through the interface.
PVID Port VLAN ID.
Mdi type Cable type.
Port link-type Link type of the interface: access, trunk, or hybrid.
Tagged VLAN ID
VLANs for which the interface sends packets without removing VLAN
tags.
Untagged VLAN ID
VLANs for which the interface sends packets after removing VLAN
tags.
Last clearing of counters: Never
Time when the reset counters interface command was last used to clear
statistics on the interface. Never indicates that the reset counters
interface command was never used since the device was started.
Peak value of input Peak value of inbound traffic, in Bps.
Peak time of input Time of peak inbound traffic.
Peak value of output Peak value of outbound traffic, in Bps.
Peak time of output Time of peak outbound traffic.
