12
Field Description
Last 300 seconds input: 0
packets/sec 0 bytes/sec
Last 300 seconds output: 0
packets/sec 0 bytes/sec
Average rate of input and output traffic in the last 300 seconds, in pps
and Bps.
The statistics polling interval, 300 seconds in this example, can be
configured by using the flow-interval command.
Input (total): 21322 packets,
1748554 bytes
- unicasts, - broadcasts, -
multicasts, - pauses
Inbound traffic statistics (in packets and bytes) for the interface. All
inbound normal and abnormal packets (including unicast, broadcast,
and multicast), and pause frames were counted.
Input (normal): 21322 packets, -
bytes
1268 unicasts, 7560
broadcasts, 12494 multicasts, 0
pauses
Inbound normal traffic (including unicast, broadcast, and multicast)
and pause frame statistics (in packets and bytes) for the interface.
input errors Inbound packets with errors.
runts
Inbound frames that are shorter than 64 bytes, that are in correct
format, and that contain valid CRCs.
giants
Inbound frames larger than the maximum frame length supported on
the interface.
• For an Ethernet interface that does not permit jumbo frames, giants
refer to frames larger than 1536 bytes (without VLAN tags) or 1540
bytes (with VLAN tags).
• For an Ethernet interface that permits jumbo frames, giants refer to
frames larger than the maximum size of Ethernet frames that are
allowed to pass through, which is configured when you configure
jumbo frame support on the interface.
- throttles
Number of times that the port shut down because of buffer or CPU
overload.
CRC
Total number of inbound frames that had a normal length, but
contained checksum errors.
frame
Total number of inbound frames that contained checksum errors and a
non-integer number of bytes.
- overruns
Number of packets dropped because the input rate of the port
exceeded the queuing capability.
