Frame-format ESF, clock master, loopback not set
Cpos2/0/0 CT1 2 is up
Frame-format ESF, clock master, loopback not set
Cpos2/0/0 CT1 3 is up
Frame-format ESF, clock master, loopback not set
......
Cpos2/0/0 CT1 83 is up
Frame-format ESF, clock master, loopback not set
Cpos2/0/0 CT1 84 is up
Frame-format ESF, clock master, loopback not set
Table 25 Command output
Field Description
Cpos2/0/0 current state: Current physical state of the CPOS interface.
Description: Interface description.
Frame-format SDH, multiplex AU-3,
clock master, loopback not set
Physical layer information of the CPOS interface: the framing format
is set to SDH, AU-3 path is adopted, master clock (internal clock
signal) is used, and loopback is disabled.
SD threshold: 6 , SF threshold: 3 SD threshold and SF threshold of the CPOS interface.
Optical Transmission medium.
Tx: J0: 0x01 Sent overhead bytes.
Rx: J0: 0x01 Received overhead bytes.
Regenerator section: Alarm and error statistics about the regenerator section.
Multiplex section: Alarm and error statistics about the multiplex section.
Higher order path(VC-3-x):
Alarm and error statistics about the higher-order path. The x in
"VC-3-x" indicates the path number. When adopting AU-3 path,
one STM-1 has three higher-order paths because it is multiplexed by
three VC-3s. In the AU-4 path, there is one higher-order path VC-4.
Alarm: Alarm statistics.
Error: Error statistics.
Cpos2/0/0 CT1 1 is up
Current physical state of T1 channel 1 of the CPOS interface
2/0/0.
Frame-format ESF, clock master,
loopback not set
Physical layer information of T1 channels: the framing format is set
to ESF, master clock (internal clock signal) is used, and loopback is
disabled.
Related commands
• display controller cpos e1
• display controller cpos t1
display controller cpos e1
Use display controller cpos e1 to display the physical layer configuration information of the specified E1
channel on the specified CPOS interface.
