R3303-HP HSR6800 Routers Interface Command Reference

205
Cpos2/0/0 CE1 1 is up
Frame-format NO-CRC4, clock slave, loopback not set
E1 framer(1-1-1-1):
Alarm: none
Error: 0 FERR, 0 FEBE, 0 AERR
Table 26 Command output
Field Description
Cpos2/0/0 current state Current physical state of the CPOS interface.
Frame-format SDH, multiplex AU-4,
clock master, loopback not set
Physical layer information of the CPOS interface.
In this sample output, the framing format is set to SDH, AU-4 path is
adopted, master clock (internal clock signal) is used, and loopback
is disabled.
Tx: J0: 0x01 Sent overhead bytes.
Rx: J0: 0x01 Received overhead bytes.
Regenerator section: Alarm and error statistics about the regenerator section.
Multiplex section: Alarm and error statistics about the multiplex section.
Higher order path(VC-4-1):
Alarm and error statistics of the E1 path. VC-4-1 represents the
second VC-4.
Lower order path Alarm and error statistics of the lower order E1 path.
Alarm: Alarm statistics.
Error: Error statistics.
Cpos2/0/0 CE1 1 is up Current physical state of E1 channel 1 of CPOS 2/0/0.
Frame-format, clock, loopback
Physical layer information of E1 channels.
In this sample output, the framing format is set to NO-CRC4, slave
clock mode is used, and loopback is disabled.
E1 framer(1-1-1-1)
Indicates how the E1 channel is multiplexed. 1-1-1-1 represents in
order VC-4 number, TUG-3 number, TUG-2 number, and TU-12
number for an E1 channel.
display controller cpos e3
Use display controller cpos e3 to display the physical layer configuration of the specified E3 channel on
the specified CPOS interface.
Syntax
display controller cpos cpos-number e3 e3-number [ | { begin | exclude | include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
