208
Examples
# Display the status information of T1 channel 2 on interface CPOS 2/0/0.
<Sysname> display controller cpos 2/0/0 t1 2
Cpos2/0/0 current state : UP Frame-format SDH, multiplex AU-3, clock master, loopback
not set
Tx: J0: 0x01
Rx: J0: 0x01
Regenerator section:
Alarm: none
Error: 0 BIP, 0 SEF
Multiplex section:
Alarm: none
Error: 0 BIP, 0 REI
Higher order path(VC-3-2):
Alarm: none
Error: 0 BIP, 0 REI
Lower order path:
Alarm: none
Error: 4095 BIP, 2047 REI
Cpos2/0/0 CT1 2 is up
Frame-format ESF, clock master, loopback not set
T1 framer(2-1-1):
Alarm: none
Error: 4095 FERR, 79 AERR
Table 29 Command output
Field Description
Cpos2/0/0 current state Current physical state of the CPOS interface.
Frame-format SDH, multiplex AU-3,
clock master, loopback not set
Physical layer information of the CPOS interface. The framing format is
set to SDH, AU-3 path is adopted, master clock (internal clock signal) is
used, and loopback is disabled.
Tx: J0: 0x01 Sent overhead bytes.
Rx: J0: 0x01 Received overhead bytes.
Regenerator section Alarm and error statistics about the regenerator section.
Multiplex section Alarm and error statistics about the multiplex section.
Higher order path(VC-3-2)
Alarm and error statistics about the higher-order path to which the T1
channel belongs. VC-3-2 means the second VC-3.
Lower order path Alarm and error statistics about the lower-order path.
Alarm Alarm statistics.
Error Error statistics.
Cpos2/0/0 CT1 2 is up Current physical state of T1 channel 2 on interface CPOS 2/0/0.
Frame-format ESF, clock master,
loopback not set
Information about the physical layer of the T1 channel. The framing
format is set to ESF; master clock (internal clock signal) is used; loopback
is disabled.
