218
Examples
# Shut down E3 channel 1 on interface CPOS 2/0/0.
<Sysname> system-view
[Sysname] controller cpos 2/0/0
[Sysname-Cpos2/0/0] e3 1 shutdown
fe3
Use fe3 to configure the specified E3 channel to operate in FE3 mode and configure its FE3 DSU mode
or FE3 subrate.
Use undo fe3 to restore the default DSU mode or subrate.
Syntax
fe3 e3-number { dsu-mode { 0 | 1 } | subrate sub-number }
undo fe3 e3-number { dsu-mode | subrate }
Default
For an FE3 channel, the DSU mode is 1 (Kentrox) and the subrate is 34010 kbps.
Views
CPOS interface view
Default command level
2: System level
Parameters
e3-number: Number of an E3 channel on the current CPOS interface, in the range of 1 to 3.
dsu-mode: Sets the data service unit (DSU) mode for fractional E3 (FE3). Table 30 lists the
available FE3
DSU mode options:
Table 30 FE3 DSU mode options
Keyword DSU mode (vendor) Subrate range
Total number of
subrate
g
rades
0 Digital Link
358 to 34010 kbps in steps of
358 kbps
95
1 Kentrox
500 to 24500 kbps in steps of
500 kbps; 34010 kbps
50
subrate sub-number: Sets the FE3 subrate, in the range of 1 to 34010 kbps.
Usage guidelines
FE3 (also called subrate E3) is a nonstandard E3 application. Available FE3 subrate ranges and the
number of subrate grades vary with vendors. You can use the fe3 command to configure your device to
be compatible with the FE3 DSU modes listed in Table 30.
W
hen you use the fe3 command, note the following:
• The subrates available in the DSU mode set with the fe3 dsu-mode command are discrete and the
subrate set with the fe3 subrate command is approximate rather than exact. After you set a subrate,
the E3 interface works out the precise subrate (accurate to bps) closest to the approximate subrate
