51
Usage guidelines
The following cable states are available:
• Normal—The cable is in good condition.
• Abnormal—Any fault other than a short or open circuit is detected.
• Abnormal (open)—An open circuit is detected.
• Abnormal (short)—A short circuit is detected.
• Failure—The detection failed.
If the cable connection is normal, the displayed cable length is the total length of the cable.
If the cable connection has a fault, the displayed cable length is the length from the local port to the faulty
point.
Fiber ports do not support this command.
If the link of an Ethernet interface is up, testing its cable connection will cause the link to go down and
then up.
The test result is for reference only. The cable length detection error is up to 5 m (about 16 ft). If a test item
is not available, a hyphen (-) is displayed.
Examples
# Test the cable connection of GigabitEthernet 4/0/1.
<Sysname> system-view
[Sysname] interface gigabitethernet 4/0/1
[Sysname-GigabitEthernet4/0/1] virtual-cable-test
Cable status: normal, 1 metres
Pair Impedance mismatch: -
Pair skew: - ns
Pair swap: -
Pair polarity: -
Insertion loss: - db
Return loss: - db
Near-end crosstalk: - db
NOTE:
The Pair Impedance mismatch field has the following values:
• Yes—Match
• No—Mismatch
Layer 3 Ethernet interface and subinterface
configuration commands
mtu
Use mtu to set the MTU for an Ethernet interface or subinterface.
Use undo mtu to restore the default.
