89
Field Description
Source Clock Work mode of the source clock of the interface: master or slave.
Line Code Line code: AMI or HDB3.
Idle Code Idle code: 0x7E or 0xFF.
Itf type Interframe filling tag: 0x7E or 0xFF.
Itf number Number of interframe filling tags between two successive frames.
Loopback Loopback state.
Alarm State Alarm state.
Historical Statistics Statistics on the interface.
Last clearing of counters The last time when statistics on the interface was cleared.
Data in current interval (150 seconds
elapsed):
0 Loss Frame Alignment Secs, 0
Framing Error Secs,
0 CRC Error Secs, 0 Alarm Indication
Secs, 0 Loss-of-signals Secs,
0 Code Violations Secs, 0 Slip Secs, 0
E-Bit error Secs
Error statistics in the current interval.
error-diffusion restraint config
Use error-diffusion restraint config to configure the error packets diffusion restraint parameters.
Use undo error-diffusion restraint config to restore the default settings for the error packets diffusion
restraint parameters.
Syntax
error-diffusion restraint config detect-timer renew-timer threshold
undo error-diffusion restraint config
Default
The detect-timer value is 30 seconds, the renew-timer value is 600 seconds, and the threshold value is
20.
Views
System view
Default command level
2: System level
Parameters
detect-timer: Period to check error packets, in the range of 30 to 600 seconds.
renew-timer: Period after which an interface resumes its function, in the range of 120 to 2,400 seconds.
threshold: Packet error rate in percentage, in the range of 5 to 100.
