Viewing utilization data
Integrity Virtual Server Manager provides the following options for viewing utilization data. These
assume the prerequisites discussed in “Enabling collection of utilization data” (page 119) have been
met.
• Utilization meters provided by Integrity Virtual Server Manager tabs. Table 16 lists the meters
provided by Integrity Virtual Server Manager tabs. Utilization meters display current utilization
data for the associated resource. The utilization information is a 5-minute average that is
calculated and updated on 5-minute boundaries. If the utilization cannot be displayed, the
utilization meter is dimmed. A label next to the meter indicates the probable cause. For
information about these labels, see “Utilization meter status/error information” (page 137).
CPU and memory utilization are expressed as a percentage. Network and storage meters
display I/O data in terms of throughput (for example, megabytes per second). Storage meters
are labeled as “Disk I/O” but provide utilization data for any supported devices (DVDs and
tape devices as well as disks). If a network or storage I/O meter is in a device box on a
Network or Storage tab, the data is specific to the device, whether it is a virtual device in a
VM or a vPar or a physical device on the VSP; if the meter is in a vPar box, the data is an
aggregate, registering the total throughput for all virtual devices on the vPar.
Table 16 Utilization meters available on Integrity Virtual Server Manager tabs
Utilization Metrics
Integrity Virtual
Server Manager
Tab
Storage I/O
(throughput)
Network I/O
(throughput)
Memory (%)CPU (%)
VSP onlyVSP onlyVSP onlyVSP onlyVSP General
Per VM onlyPer VM onlyPer VM onlyVSP CPU utilization
per VM
VM CPU utilization
VSP Virtual
Servers
VSP (Physical Network
Interfaces column)
VM (Virtual Network
Interfaces column)
VSP Network
VSP (Physical Storage
column)
VM (Virtual Storage
column)
VSP Storage
VM or vPar onlyVM or vPar onlyVM or vPar onlyVM CPU utilization
VSP CPU utilization
per VM
VM or vPar
Properties
General
VSP (Physical Network
Interfaces column)
VM or vPar (Virtual
Network Interfaces
column)
VM or vPar
Properties
Network
