1
Goes back to the previous view, in this case the Integrity Virtual Server Manager VSP view.
When you access the Vswitch Properties view from another Integrity Virtual Server Manager
view (such as the VSP view), the link returns you to that previous Integrity Virtual Server Manager
view.
2
Displays this window in a format suitable for printing.
3
Displays virtual switch configuration information.
Screen details
Table 8 Data displayed by the Vswitch Properties General tab
DescriptionData
Name of the virtual switchVswitch Name
The status of the virtual switch:
• Up (operational)
• Down (inoperational)
• Link down (the physical network interface used by the vswitch is not running)
Status
The type of virtual switch:
• shared vswitch: can be used by more than one VM or vPar that includes a virtual network
device (virtual NIC) backed by the switch
• dedicated vswitch: can be used by only one started VM or vPar at a time
Type
The LAN interface on the host through which the network traffic flowsBacking LAN
Indicates whether the backing LAN interface supports Accelerated Virtual Input/Output. AVIO is
supported on HP Integrity VM Version 3.5 or later.
For each VM or vPar containing an AVIO device, the VSP OS and the guest OS must support
AVIO. With HP Integrity Virtual Server Manager, AVIO requires a virtual switch that has a physical
network device as the backing device (local virtual switches such as localnet are not supported).
In addition, the physical NIC that backs the virtual switch must have an AVIO-compatible driver.
For more information about AVIO requirements, see the HP Integrity Virtual Server Manager
documentation at the following website (click on the HP Matrix Operating Environment for HP-UX
tab):
http://www.hp.com/go/matrixoe/docs
Supports AVIO
The set of active VMs or vPars that are configured to use this vswitch, are currently started, and
therefore, are using the vswitch
Actively used by
The set of inactive VMs or vPars with at least one virtual network interface card in the VM or vPar
configured to use the vswitch as a backing device
Configured, but
not actively used
by
If the VSP is running HP Integrity VM Version 2.0 or greater, a table of the VLAN (virtual LAN)
port assignments, if any. (A VLAN defines the logical connectivity defined by a LAN.) This table
lists the following information:
Vswitch Port
Assignments
DescriptionData
Port IDs for the vswitchPort
If a VLAN ID has been specified for this port, it
is displayed here; otherwise, this column displays
(none)
VLAN ID
List of VMs or vPars that are assigned to this
vswitch port
Assigned to
Vswitch Properties Network tab
The Vswitch Properties Network tab shows the network details about a vswitch, including the VMs
or vPars that use the virtual switch.
