Performing an Upgrade Installation or Re-installation of HDLM
This subsection explains how to perform an upgrade installation from an
earlier version, or how to re-install HDLM.
Because HDLM version 5.8.1 or earlier cannot be upgraded to HDLM version
5.9 or later, migration is necessary. For details about migration, see
Migrating from HDLM Version 5.8.1 or Earlier to Version 5.9 or Later on page
3-61.
The following table lists and describes the files that are inherited during an
upgrade installation or re-installation of HDLM.
Table 3-11 List of Files Inherited During an Upgrade Installation or Re-
installation
File Description
/usr/DynamicLinkManager/config/dlmmgr.xml
File for setting up HDLM
functionality
/var/DynamicLinkManager/log/dlmmgr[1-16].log
Log files of HDLM
Manager
/var/DynamicLinkManager/log/dlminquiry[1-2].log
Log files of HDLM
Inquiry information
/usr/DynamicLinkManager/config/dlmwebagent.properties
Hitachi Command Suite
Common Agent
Component settings file
/var/DynamicLinkManager/log/hdlmtr[1-64].log
Trace files
/var/DynamicLinkManager/log/dlmconfig[1-2].log
Configuration log file
/var/DynamicLinkManager/log/mmap/hdlmtr.mm
Trace management file
/var/DynamicLinkManager/log/dlmwebagent[1-16].log
Hitachi Command Suite
Common Agent
Component log files
/var/DynamicLinkManager/log/dlmutil[1-2].log
HDLM utility's log file
/var/DynamicLinkManager/log/mmap/dlmutil.mm
HDLM utility's log trace
management file
/var/DynamicLinkManager/log/installhdlm.log
Unattended installation
execution log
When Installing HDLM in a Local Boot Disk Environment
1. Log in to AIX as a user with root permissions.
If you are using a virtual I/O server, see the virtual I/O server
documentation to log in to AIX.
2. Back up the HDLM settings.
If an upgrade installation or re-installation fails, AIX automatically
removes HDLM, and the HDLM settings are deleted.
Perform this step so that a copy of the HDLM settings is available in this
case.
