Even when cluster software is being used, the name of the cluster
software is not displayed in Support Cluster. However, the cluster
support function is operating normally.
25. From the execution result of the view operation, check that the correct
version of HDLM is installed.
If HDLM Version is x.x.x-xx, the installed version of HDLM is correct.
x.x.x-xx is the installed version of HDLM.
26. From the execution result of the view operation, check that the programs
are running properly.
If HDLM Manager, HDLM Alert Driver, and HDLM Driver are all Alive, all
programs are running correctly.
If you are not using a virtual I/O server, the upgrade installation or re-
installation of HDLM is complete.
For details about the files to be inherited after the upgrade installation or
re-installation of HDLM, see
Table 3-11 List of Files Inherited During an
Upgrade Installation or Re-installation on page 3-38.
27. If you are using a virtual I/O server, define an hdisk as a virtual target
device.
Execute the following command on the virtual I/O server:
When creating an hdisk as a virtual target device:
$ mkvdev -vdev hdisk-name -vadapter virtual-SCSI-server-
adapter-name
When creating a logical device as a virtual target device:
$ mkvdev -vdev logical-volume-name -vadapter virtual-SCSI-
server-adapter-name
28. Execute the following command in the client logical partition to
reconfigure the device:
# cfgmgr
29. Execute the following command in the client logical partition to confirm
that the physical volume has been recognized as hdisk.
If the following message is displayed, then the physical volume (hdisk)
was recognized correctly.
# lsdev -Cc disk
hdisk1 Available Virtual SCSI Disk Drive
When Installing HDLM in a Boot Disk Environment
1. Log in to AIX as a user with root permissions.
If you are using a virtual I/O server, see the virtual I/O server
documentation to log in to AIX.
2. Back up the HDLM settings.
If an upgrade installation or re-installation fails, AIX automatically
removes HDLM, and the HDLM settings are deleted.
