When the license key file has been provided
Store the license key file directly under the /var/tmp/ directory on a
NIM client by using the hdlm_license name.
/var/tmp/hdlm_license
On the NIM client, execute the set operation of the HDLM command
while specifying the -lic parameter.
# /usr/DynamicLinkManager/bin/dlnkmgr set –lic
KAPL01049-I Would you like to execute the operation?
Operation name = set [y/n]:y
KAPL01071-I The permanent license was installed.
#
For details about license key types and the set operation, see
set (Sets
Up the Operating Environment) on page 6-18.
2. Log in to the NIM master as a user with root privileges.
3. On the NIM master, execute the following nimadm command:
# nimadm -c NIM-client-name -l NIM-resource-containing-HDLM -s
NIM-SPOT-name -d NIM-client-target-disk... -Y
For details about the nimadm command, see the AIX documentation.
4. After restarting the NIM client from the alternate disk, execute the
following command on the NIM client to confirm that the package has
been installed:
# lslpp -la DLManager.mpio.rte
Make sure that DLManager.mpio.rte exists among the file set items on
the output list, and that only the COMMITTED status is displayed.
If there is even one BROKEN status displayed, remove HDLM and then
perform a new installation, or re-create the alternate disk.
5. On the NIM client, execute the view operation of the HDLM command to
display the status of each program.
The following is an example of executing the command:
# /usr/DynamicLinkManager/bin/dlnkmgr view -sys
HDLM Version : x.x.x-xx
Load Balance : on(rr)
Support Cluster :
Elog Level : 3
Elog File Size (KB) : 9900
Number Of Elog Files : 2
Trace Level : 0
Trace File Size(KB) : 1000
Number Of Trace Files : 4
Path Health Checking : on(30)
Auto Failback : off
Intermittent Error Monitor : off
Dynamic I/O Path Control : off(10)
HDLM Manager Ver WakeupTime
Alive x.x.x-xx yyyy/mm/dd hh:mm:ss
HDLM Alert Driver Ver WakeupTime ElogMem Size
Alive x.x.x-xx yyyy/mm/dd hh:mm:ss 4000
HDLM Driver Ver WakeupTime
Alive x.x.x-xx yyyy/mm/dd hh:mm:ss
