The following is an example of executing the command to check the
location of spot_7102_HDLM when the name of the SPOT to which
HDLM is installed is spot_7102_HDLM:
# lsnim -l spot_7102_HDLM | grep location
location = /export/spot_7102/spot_7102_HDLM/usr
In the above example, the license key file will be /export/
spot_7102/spot_7102_HDLM/usr/lpp/bos/inst_root/var/tmp/
hdlm_license.
3. Execute the following command to perform a new or upgrade installation:
# nim -o cust -a lpp_source=Ipp-source-resources-that-contain-
HDLM -a filesets=DLManager.mpio.rte NIM-SPOT-name-of-HDLM-
installation-destination
For details about the nim command, see the AIX documentation.
4. Execute the following command to perform a reinstallation:
# nim -o cust -a lpp_source=Ipp-source-resources-that-contain-
HDLM -a filesets=DLManager.mpio.rte -a installp_flags=aXF NIM-
SPOT-name-of-HDLM-installation-destination
For details about the nim command, see the AIX documentation.
5. Execute the following command to verify that the package has been
installed:
# nim -o lslpp name-of-NIM-SPOT-where-HDLM-is-installed
Make sure that the fileset item in the output listing contains
DLManager.mpio.rte, and that the State item is COMMITTED.
If the State item is a value other than COMMITTED, uninstall
DLManager.mpio.rte, and then repeat the installation procedure to the
SPOT.
6. If you installed HDLM to a SPOT, and you then use that SPOT to install
the operating system to a NIM client, after the installation, perform the
procedure below to run the utility for HDLM restoration support
(dlmpostrestore).
a. After the OS is installed and the host starts, log in to that host as the
root user.
b. Execute the dlmpostrestore utility.
# /usr/DynamicLinkManager/bin/dlmpostrestore
A message (in a local boot disk environment, the KAPL10552-I
message, or in a boot disk environment, the KAPL10555-I message)
appears and asks for confirmation that processing is to continue. To
continue the processing, enter y. In a boot disk environment, the host
restarts.
For details about the dlmpostrestore utility, see
dlmpostrestore Utility
for HDLM Restoration Support on page 7-25.
