Because HDLM version 5.9 or later requires deletion of hdisk, do not
attempt to perform device configuration (cfgmgr command) before
performing step 17.
16. Perform a new installation of HDLM version 5.9 or later.
Perform steps 4 to 9 of
When Installing HDLM in a Local Boot Disk
Environment on page 3-26 in Performing a New Installation of HDLM on
page 3-26. Note that you do not have to perform steps 2 to 3.
17. Execute the dlmmigsts utility to restore the HDLM environment settings
information and the HDLM execution environment ODM settings that you
saved in step 14.
# /cdrom/HDLM_AIX/hdlmtool/dlmmigsts -r -odm /tmp/any-desired-
directory/odm-environment-settings-file-name -set /tmp/any-
desired-directory/set-environment-settings-file-name
For details about the dlmmigsts utility, see
dlmmigsts Utility for Assisting
HDLM Migration on page 7-20.
18. Execute the following command to reconfigure the device:
# cfgmgr
19. Make sure that the HDLM settings information has been properly
inherited.
¢
Make sure that the HDLM environment settings information has been
properly inherited.
Execute the following command, and then compare the current HDLM
environment settings information with the settings information saved
in step 13:
# /usr/DynamicLinkManager/bin/dlnkmgr view -sys
¢
Make sure that the HDLM execution environment ODM settings
information has been properly inherited.
Execute the following command, and then compare the current HDLM
execution environment ODM settings information with the settings
information saved in step 13:
# /usr/DynamicLinkManager/bin/dlmodmset -o
If the HDLM settings information has been properly inherited, skip to step
21.
20. If the HDLM settings information has not been properly inherited, execute
the following command:
# /usr/DynamicLinkManager/bin/dlmrmdev
Check the file names for odm-environment-settings-file-name and set-
environment-setting-file-name, and then perform this procedure again
from step 17, specifying the correct file names in the command.
21. Delete the odm environment settings file and the set environment settings
file.
# rm -r /tmp/any-desired-directory-that-stores-odm-environment-
settings-file
