# rm -r /tmp/any-desired-directory-that-stores-set-environment-
setting-file
22. Perform the procedure described in When Installing HDLM in a Local Boot
Disk Environment on page 3-26 in Performing a New Installation of HDLM
on page 3-26, starting from step 14.
23. If you performed step 5, restore the volume group you backed up.
# restvg -f any-desired-file-name-or-device-name hdisk-name
24. Check the path configuration according to the steps described in
Checking
the Path Configuration on page 3-77.
25. Unmount the DVD-ROM.
# umount /cdrom
26. Delete any mount directory you may have created in step 11.
# rm -r /cdrom
Installing HDLM in a PowerHA 6.1 Environment
This subsection explains how to install HDLM when you are running services
in a PowerHA 6.1 environment.
Upgrading or Re-installing HDLM in a PowerHA 6.1 Environment (in a Local Boot
Disk Environment)
Because HDLM version 5.8.1 or earlier cannot be upgraded to HDLM version
5.9 or later, migration is necessary. For details about migration, see
Migrating HDLM in a PowerHA 6.1 Environment on page 3-65.
For details about setting up PowerHA, see the PowerHA documentation.
To upgrade or re-install HDLM in an environment that uses PowerHA
and a local boot disk:
1. Log in to AIX as the root user.
If you are using a virtual I/O server, see the virtual I/O server
documentation to log in to AIX.
2. Stop PowerHA on the standby host.
3. Upgrade or re-install HDLM on the standby host.
To do so, perform steps 2 through 23 in
When Installing HDLM in a Local
Boot Disk Environment on page 3-38 of Performing an Upgrade
Installation or Re-installation of HDLM on page 3-38 on the standby host.
4. Start PowerHA on the standby host.
5. Stop PowerHA on the active host.
Specify takeover as the shutdown mode.
6. Upgrade or re-install HDLM on the active host.
To do so, perform steps 2 through 23 in
When Installing HDLM in a Local
Boot Disk Environment on page 3-38 of Performing an Upgrade
Installation or Re-installation of HDLM on page 3-38 on the active host.
