Installing HDLM in an Environment Running PowerHA 7.1 or a Later
Version
In an environment running PowerHA 7.1 or a later version, even if the cluster
service is stopped, the cluster repository disk remains in the used state.
Therefore, if you perform a new installation, upgrade installation, or re-
installation of HDLM in an environment in which PowerHA is already in use,
perform the procedure below. For details on how to use and set up PowerHA,
see the PowerHA documentation.
1. Log in to the standby host as the root user.
2. Execute the following command on the standby host to stop PowerHA.
# smitty cl_stop
3. Execute the following command on the standby host.
When the OS used in a PowerHA environment is AIX V6.1 TL06 or AIX
V7.1 with no TL:
# clcmd stopsrc -s clconfd
# clusterconf -fu
When the OS used in a PowerHA environment is AIX V6.1 TL07 or later or
AIX V7.1 TL01 or later:
# clctrl -stop -m node-name
4. Perform a new installation, upgrade installation, or re-installation of HDLM
on the standby host.
When performing a new installation of HDLM in a local boot disk
environment:
Perform the procedure described in Stop Applications on page 3-37 of
Preparations for an Upgrade Installation or Re-installation of HDLM on
page 3-37.
When performing a new installation of HDLM in a boot disk environment:
Perform the procedure described in Perform Operations for HDLM
Management-Target Device on page 3-37 of Preparations for an
Upgrade Installation or Re-installation of HDLM on page 3-37.
When performing an upgrade installation or re-installation of HDLM in a
local boot disk environment:
Perform the procedure described in When Installing HDLM in a Local
Boot Disk Environment on page 3-38 of Performing an Upgrade
Installation or Re-installation of HDLM on page 3-38.
When performing an upgrade installation or re-installation of HDLM in a
boot disk environment:
Perform the procedure described in When Installing HDLM in a Boot
Disk Environment on page 3-45 of Performing an Upgrade Installation
or Re-installation of HDLM on page 3-38.
