If the directory that contains the license key or the license key file is
specified in the installation information settings file, you can use any
storage directory name and file name.
The following shows examples of when the default storage directory
specified in the installation information settings file is to be used:
¢
When only the license key has been provided
Create the /var/DLM directory, and then, in this directory, create the
license key file (dlm.lic_key). The following shows an example when
the license key is 123456789ABCDEF:
# mkdir /var/DLM
# echo "123456789ABCDEF" > /var/DLM/dlm.lic_key
¢
When the license key file has been provided
Store the license key file directly under the /var/tmp/ directory by
using the hdlm_license name.
/var/tmp/hdlm_license
The license key file or license key is not deleted after the installation.
8. Create an installation information settings file.
To use the sample file, copy it from the DVD-ROM to a directory on the
hard disk.
# cp -p /cdrom/HDLM_AIX/hdlmtool/instutil/
sample_installhdlm.conf /any-directory
You can change the sample_installhdlm.conf file name.
The following shows an example of copying the
sample_installhdlm.conf file, and then changing the file name to
install_set.conf:
# cp -p /cdrom/HDLM_AIX/hdlmtool/instutil/
sample_installhdlm.conf /any-directory/install_set.conf
For details about how to edit the installation information settings file,
which is used by the installhdlm utility, see
Items To Be Defined in an
installation-information Settings File on page 7-33.
9. Execute either of the following commands:
To execute
installux.sh:
# /cdrom/installux.sh -f /any-directory/installation-
information-settings-file
To execute installhdlm:
# /cdrom/HDLM_AIX/hdlmtool/instutil/installhdlm -f /any-
directory/installation-information-settings-file
Even though a message asking you to restart the host is displayed during
installation, you do not have to restart the host. When installation is
successful, the KAPL09211-I message is output.
During installation, the KAPL09241-W message might be output. In this
case, installation of HDLM continues, but installation of HDLM components
