has failed. After installing HDLM, resolve the problem according to the
KAPL09241-W message if necessary.
For an upgrade installation or re-installation of HDLM, the configuration of
the existing hdisks recognized as HDLM management-target devices is
inherited.
10. Unmount the DVD-ROM.
# umount /cdrom
11. Delete the created mount directory.
# rm -r /cdrom
12. Delete the installation information settings file.
# rm -r /directory-containing-the-installation-information-
settings-file
13. Perform the procedure appropriate for the installation type.
If you are performing a new installation, perform steps 14 to the end of
the procedure described in When Installing HDLM in a Local Boot Disk
Environment on page 3-26 of Performing a New Installation of HDLM on
page 3-26.
If you are performing an upgrade installation or a re-installation, perform
steps 15 to the end of the procedure described in
When Installing HDLM
in a Local Boot Disk Environment on page 3-38 of Performing an Upgrade
Installation or Re-installation of HDLM on page 3-38.
When Installing HDLM in a Boot Disk Environment
To install HDLM in a boot disk environment:
1. For AIX 5.3, use a single-path configuration for host and storage systems.
For AIX 6.1 or AIX 7.1, you can use a single-path configuration or a multi-
path configuration for host and storage systems.
2. Log in to AIX as the root user.
If you are using a virtual I/O server, see the virtual I/O server
documentation to log in to AIX.
3. If you are performing a new installation, and the boot disk is in a multi-
path configuration, execute the commands below to confirm that the
physical volume containing the boot logical volume hd5 is the same as the
physical volume used for booting.
If the boot disk is in a single-path configuration, you do not have to
perform this step.
ยข
Identify the physical volume that contains the boot logical volume
hd5:
# lsvg -M rootvg | grep -w hd5
hdisk3:1 hd5:1
In this example, hdisk3 contains the boot logical volume hd5.
