Setting up HDLM
HDLM includes functions like the load balancing function, the automatic
failback function, the error logging function, the audit logging function, etc.
You can set up these functions by using the dlnkmgr command's set
operation. The following subsections describe these setup methods.
Checking the Current Settings
This chapter describes how to check the HDLM function settings before any
changes are made by using the dlnkmgr command's view operation.
Check the current settings by executing the following command:
# /usr/DynamicLinkManager/bin/dlnkmgr view -sys -sfunc
HDLM Version : x.x.x-xx
Service Pack Version :
Load Balance : on(extended lio)
Support Cluster :
Elog Level : 3
Elog File Size(KB) : 9900
Number Of Elog Files : 2
Trace Level : 0
Trace File Size(KB) : 1000
Number Of Trace Files : 4
Path Health Checking : on(30)
Auto Failback : on(60)
Intermittent Error Monitor : off
Dynamic I/O Path Control : off(10)
KAPL01001-I The HDLM command completed normally. Operation name =
view, completion time = yyyy/mm/dd hh:mm:ss
#
To check the current audit log settings, execute the following command:
# /usr/DynamicLinkManager/bin/dlnkmgr view -sys -audlog
Audit Log : off
Audit Log Category : -
Audit Log Facility : -
KAPL01001-I The HDLM command completed normally. Operation name =
view, completion time = yyyy/mm/dd hh:mm:ss
#
Setting Up the HDLM Functions
The table below summarizes the functions that can be set in HDLM. For
details about each function, see
Setting Up Load Balancing on page 3-80
and subsequent sections.
Each function has a default value and a recommended value. If no function is
set by the HDLM command's set operation, the default value is applied for
each function. The recommended values are used as the guideline values
when functions are configured.
