Table 3-12 The Recommended and Default Values of Each Function
Function Default value Recommended value
Load-balancing
on
The Extended Least I/Os
algorithm is used.
on
The recommended algorithm
depends on the operating
environment.
Path health checking
on
30-minute check interval
on
The recommended checking
interval depends on the
operating environment.
Automatic failback
on
60-minute check interval
The recommended checking
interval depends on the
operating environment.
Intermittent Error
Monitor
off on
The recommended checking
interval depends on the
operating environment.
Dynamic I/O path
control
#
off
10-minute check interval
off
The recommended checking
interval depends on the
operating environment.
Logging level 3: Collects all the error
information for the
"Information" level or higher
3: Collects all the error
information for the
"Information" level or higher
Trace level 0: Do not output trace files 0: Do not output trace files
File size for the Error
log
9900 (KB) 9900 (KB)
Number of files for the
Error logs
2 2
File size for trace
information
1000 (KB) 1000 (KB)
Number of files for trace
information
4 4
Collection of audit log
data
off
The recommended value
depends on the operating
environment.
Set on, if you want to collect
audit log data.
Audit log facility user local0 to local7
#
This function is applied only when Hitachi AMS2000 series, Hitachi SMS
series, or HUS100 series storage is used.
