3. Check to see if the statuses of all the applicable paths have changed.
The following example shows how to execute the command:
# /usr/DynamicLinkManager/bin/dlnkmgr view -path
Viewing LU Information
This section explains how to display LU information by using an HDLM
command.
To display LU information, execute the dlnkmgr command's view operation
with the -lu parameter specified. The following shows an example in which
the command is executed:
# /usr/DynamicLinkManager/bin/dlnkmgr view -lu
Product : USP
SerialNumber : 0014010
LUs : 10
iLU HDevName OSPathID PathID Status
003A hdisk0 00000 000000 Online
00001 000001 Online
003B hdisk1 00000 000002 Online
00001 000003 Online
003C hdisk2 00000 000004 Online
00001 000005 Online
003D hdisk3 00000 000006 Online
00001 000007 Online
003E hdisk4 00000 000008 Online
00001 000009 Online
003F hdisk5 00000 000010 Online
00001 000011 Online
0040 hdisk6 00000 000012 Online
00001 000013 Online
0041 hdisk7 00000 000014 Online
00001 000015 Online
0042 hdisk8 00000 000016 Online
00001 000017 Online
0043 hdisk9 00000 000018 Online
00001 000019 Online
KAPL01001-I The HDLM command completed normally. Operation name =
view, completion time = yyyy/mm/dd hh:mm:ss
#
For details on the displayed items and their descriptions, see
view (Displays
Information) on page 6-34.
Displaying the Correspondences Between hdisks, OS Management
Path IDs, and LDEVs
This section explains the use of an HDLM command to display the
correspondences between hdisks, OS management path IDs, and LDEVs.
You display this information by executing the HDLM command's view
operation with the -drv parameter specified. For details on the view
4-8
HDLM Operation
Hitachi Dynamic Link Manager (for AIX) User Guide
