operation, see view (Displays Information) on page 6-34. The execution
result of this operation is displayed on a single line for each path.
The following shows an example in which the view operation is executed:
# /usr/DynamicLinkManager/bin/dlnkmgr view -drv
PathID HDevName OSPathID LDEV
000000 hdisk0 00000 9500V.0051.0005
000001 hdisk1 00000 9500V.0051.0015
000002 hdisk2 00000 9500V.0051.0020
000003 hdisk0 00001 9500V.0051.0005
000004 hdisk1 00001 9500V.0051.0015
000005 hdisk2 00001 9500V.0051.0020
KAPL01001-I The HDLM command completed normally. Operation name =
view, completion time = yyyy/mm/dd hh:mm:ss
#
For details on the displayed items and their descriptions, see
view (Displays
Information) on page 6-34.
Initializing Statistical Information for Paths
This section explains how to initialize statistical information (I/O counts and
I/O errors) for all the paths managed by HDLM.
This procedure is useful when you want to check the number of I/O
operations and I/O errors that have occurred since the last time the I/O
counts and I/O errors were initialized to 0.
To initialize statistical information for paths:
1. Check the current status of the path.
The following shows how to execute the command:
# /usr/DynamicLinkManager/bin/dlnkmgr view -path
2. To initialize statistical information for all the paths managed by HDLM,
execute the dlnkmgr command's clear operation with the -pdst
parameter specified.
The following shows an example in which the command is executed:
# /usr/DynamicLinkManager/bin/dlnkmgr clear -pdst
KAPL01049-I Would you like to execute the operation? Operation
name = clear [y/n]:y
KAPL01001-I The HDLM command completed normally. Operation name
= clear, completion time = yyyy/mm/dd hh:mm:ss
#
3. Check to see whether the statistical information for all the paths has been
initialized.
The following shows how to execute the command:
# /usr/DynamicLinkManager/bin/dlnkmgr view -path
