Viewing and Setting Up the Operating Environment
This section explains how to display and set up the HDLM operating
environment.
Viewing the Operating Environment
To display the operating environment, execute the dlnkmgr command's view
operation with the -sys and -sfunc parameters specified.
The following shows an example in which the command is executed:
# /usr/DynamicLinkManager/bin/dlnkmgr view -sys -sfunc
HDLM Version : x.x.x-xx
Service Pack Version :
Load Balance : on(extended lio)
Support Cluster :
Elog Level : 3
Elog File Size(KB) : 9900
Number Of Elog Files : 2
Trace Level : 0
Trace File Size(KB) : 1000
Number Of Trace Files : 4
Path Health Checking : on(30)
Auto Failback : on(60)
Intermittent Error Monitor : off
Dynamic I/O Path Control : off(10)
KAPL01001-I The HDLM command completed normally. Operation name =
view, completion time = yyyy/mm/dd hh:mm:ss
#
To display the operating environment of the audit log, execute the HDLM
command's view operation with the -sys and -audlog parameters specified.
The following example shows how to execute the command:
# /usr/DynamicLinkManager/bin/dlnkmgr view -sys -audlog
Audit Log : off
Audit Log Category : -
Audit Log Facility : -
KAPL01001-I The HDLM command completed normally. Operation name =
view, completion time = yyyy/mm/dd hh:mm:ss
#
For details on the displayed items and their descriptions, see
view (Displays
Information) on page 6-34.
Setting Up the Operating Environment
To set up the HDLM operating environment, execute the dlnkmgr command's
set operation. This operation allows you to set up the following functions:
• Load balancing
• Path health checking
• Automatic failback
• Intermittent error monitoring
