# /usr/DynamicLinkManager/bin/dlnkmgr view -sys -msrv
HDLM Manager Ver WakeupTime
Dead
KAPL01001-I The HDLM command completed normally. Operation name =
view, completion time = yyyy/mm/dd hh:mm:ss
#
When the HDLM Manager column shows Dead, the HDLM manager is inactive.
HDLM Resident Processes
The table below lists and describes the resident processes in HDLM. To
monitor these processes, use the names below.
Table 4-1 HDLM resident processes
Process Description
dlmmgr
HDLM manager process
hbsa_service
Hitachi Command Suite Common Agent Component
#
process
hntr2mon
Hitachi Network Objectplaza Trace Library (HNTRLib2) process
#
You only need to monitor this process when HDLM is linked to Global Link
Manager.
Changing the Configuration of the HDLM Operating
Environment
This chapter describes the procedures for changing the configuration of an
HDLM operating environment.
Changing an HDLM Management-Target Device
This subsection explains how to add and delete HDLM management-target
devices and how to change their attributes.
Adding an HDLM Management-Target Device
Connect the device to the system and execute the following command:
# cfgmgr
Deleting an HDLM Management-Target Device
1. Execute the following command to check the device (hdisk) to be deleted:
# /usr/DynamicLinkManager/bin/dlnkmgr view -path
HDLM Operation
4-15
