# /usr/DynamicLinkManager/bin/dlnkmgr help help
help:
Format
dlnkmgr help { clear | offline | online | set | view | add |
delete }
KAPL01001-I The HDLM command completed normally. Operation name
= help, completion time = yyyy/mm/dd hh:mm:ss
#
offline (Places Paths Offline)
The dlnkmgr command's offline operation places online paths offline.
Specify the paths to be placed offline by specifying an HBA port, CHA port,
single path, or host device.
There must always be at least one online path accessing each LU.
Placing too many paths offline might prevent paths from being able to switch
if an error occurs. Before placing a path offline, use the view operation to
check how many online paths remain. For details about the view operation,
see
view (Displays Information) on page 6-34.
Format
To Place Paths Offline
/usr/DynamicLinkManager/bin/dlnkmgr offline
[-path]
{-hba HBA-adapter-number.bus-number-or-adapter-type.adapter-
number
|-hbaid HBA-port-ID
|-cha -pathid AutoPATH_ID
|-chaid CHA-port-ID
|-pathid AutoPATH_ID
|-hdev host-device-name -ospathid OS-management-path-ID}
[-s]
To Display the Format of the Offline Operation
/usr/DynamicLinkManager/bin/dlnkmgr offline -help
Parameters
To Place Paths Offline
-path
Indicates that the target of the operation is a path managed by HDLM.
