Table 6-2 Default and Recommended Values
Item name Default value Recommended value
Load balancing
on
The Extended Least I/Os
algorithm is used.
on
The recommended algorithm
depends on the operating
environment.
Error log collection
level
3: Collect error information for
the Information level and
higher.
3: Collect error information for
the Information level and higher.
Error log file size 9900 (KB) 9900 (KB)
Number of error
log files
2 2
Trace level 0: Do not output any trace. 0: Do not output any trace.
Trace file size 1000 (KB) 1000 (KB)
Number of trace
files
4 4
Path health
checking
on (Interval is 30 minutes.)
on
The recommended checking
interval depends on the operating
environment.
Automatic failback on (Interval is 60 minutes.) The recommended checking
interval depends on the operating
environment.
Intermittent error
monitoring
off on
The recommended checking
interval depends on the operating
environment.
Collecting audit log
data
off
The recommended value depends
on the operating environment.
Set on, if you want to collect
audit log data.
Audit log facility
user
local0 to local7
Number of times
the same path can
be used for load
balancing
20
The recommended value depends
on the operating environment.
Number of times
the same path can
be used for
extended load
balancing
100
The recommended value depends
on the operating environment.
Dynamic I/O path
control
#
off
The checking interval is 10
minutes.
off
The recommended checking
interval depends on the operating
environment.
