Value Corresponding facility value in the /etc/syslog.conf file
local1 or 17
local1
local2 or 18
local2
local3 or 19
local3
local4 or 20
local4
local5 or 21
local5
local6 or 22
local6
local7 or 23
local7
-lbpathusetimes number-of-path-use-times
Specifies the number of times the same path can be used for I/O
operations when the Round Robin (rr), Least I/Os (lio), or Least Blocks
(lbk) algorithm is used for load balancing.
You can specify a decimal (base 10) value from 0 to 999999. The default
is 20.
If you specify 0, operation is the same as when load balancing is disabled.
-expathusetimes number-of-path-use-times
Specifies the number of times the same path can be used for sequential
I/O operations when the extended Round Robin (exrr), Least I/Os
(exlio), or Least Blocks (exlbk) algorithm is used for load balancing.
You an specify a decimal (base 10) value from 0 to 999999. The default is
100.
If you specify 0, the same path is used as long as the sequential I/O
operations continue.
-dpc {on|off} [-pathid path-ID -lu | -pathid path-ID -storage]
Enables or disables the dynamic I/O path control function for each
storage system or LU. The default value is "off".
on: Enabled
off: Disabled
-pathid path-ID -lu
Sets the dynamic I/O path control function to enabled or disabled for
each LU. Specify one of the IDs of the paths connected to the target
LU.
-pathid path-ID -storage
Sets the dynamic I/O path control function to enabled or disabled for
each storage system. Specify one of the IDs of the paths connected to
the target storage system.
If the -pathid parameter is not specified, the setting is performed for
each system, and the setting for each storage system or LU is cleared.
-dpcintvl checking-interval
Command Reference
6-31
Hitachi Dynamic Link Manager (for AIX) User Guide
