[-hbaportwwn]
[-t]
To display path information (by selecting a display item)
/usr/DynamicLinkManager/bin/dlnkmgr view -path -item
[pn] [dn] [lu] [cp] [type] [ic] [ie] [dnu] [hd] [iep]
[hbaportwwn] [phys] [virt] [vid] [ha]
[-pstv|-vstv]
[-hdev host-device-name]
[-stname]
[-srt {pn|lu|cp}]
[-t]
To display a summary of path information
/usr/DynamicLinkManager/bin/dlnkmgr view -path -c
[-pstv|-vstv]
[-stname]
[-srt {lu|cp}]
[-t]
To Display LU Information
To display LU information
/usr/DynamicLinkManager/bin/dlnkmgr view -lu
[-pstv|-vstv]
[-hdev host-device-name | -pathid AutoPATH_ID]
[-t]
To display LU information (by adding items to be displayed)
/usr/DynamicLinkManager/bin/dlnkmgr view -lu -item
[ [slpr] [pn] [cp] [clpr] [type] [ic] [ie] [dnu] [iep]
[vg] [dpc] [phys] [virt] [vid] [ha] [hastat] | all ]
[-pstv|-vstv]
[-hdev host-device-name | -pathid AutoPATH_ID]
[-t]
To display a summary of LU information
/usr/DynamicLinkManager/bin/dlnkmgr view -lu -c [-pstv|-vstv] [-
t]
