To display a summary of LU information (by adding items to be
displayed)
/usr/DynamicLinkManager/bin/dlnkmgr view -lu -c -item
[[slpr] [vg] | all ]
[-pstv|-vstv]
[-t]
To Display HBA Port Information
/usr/DynamicLinkManager/bin/dlnkmgr view -hba [-srt pb] [-
portwwn] [-t]
To Display CHA Port Information
/usr/DynamicLinkManager/bin/dlnkmgr view -cha [-srt cp] [-t]
Correspondences Between hdisks, OS Management Path IDs, and LDEVs
/usr/DynamicLinkManager/bin/dlnkmgr view -drv [-pstv|-vstv] [-t]
To Display the Format of the View Operation
/usr/DynamicLinkManager/bin/dlnkmgr view -help
Parameters
This section describes the parameters for the view operation, in the following
order:
To Display Program Information on page 6-36
To Display Path Information on page 6-44
To Display LU Information on page 6-57
To Display HBA Port Information on page 6-70
To Display CHA Port Information on page 6-71
To Display the Correspondences Between hdisks, OS Management Path IDs,
and LDEVs on page 6-73
To Display the Format of the View Operation on page 6-74
To Display Program Information
-sys
[-sfunc|-msrv|-adrv|-pdrv|-lic|-audlog|-lbpathusetimes|-
expathusetimes|-pstv]
Displays the HDLM program information.
Use one of the sub-parameters (following -sys) to specify the program
information that you want to display. If you do not specify a sub-
parameter, the command displays all of the program information except
the information about the audit log data collection settings, the number of
6-36
