Parameter
and
program
informatio
n to be
displayed
Item Description
• 3: Collects error information at the Information
level or higher.
• 4: Collects error information at the Information
level or higher (including maintenance
information).
Elog File Size
(KB)
Size of the error log file in kilobytes
Number Of Elog
Files
Number of error log files
Trace Level Trace output level:
• 0: Does not output any trace.
• 1: Only outputs error information.
• 2: Outputs a summary of program operation.
• 3: Outputs details of program operation.
• 4: Outputs all information.
Trace File
Size(KB)
Trace file size in kilobytes
Number Of
Trace Files
Number of trace files.
Path Health
Checking
• Settings for path health checking:
on: Enabled
off: Disabled
• Checking interval:
When the setting of the path health checking is
on, the checking interval of path health checking
is displayed within the parentheses following on.
The time is in minutes.
Auto Failback • Settings for an automatic failback:
on: Enabled
off: Disabled
• Checking interval:
When the setting of the automatic failback is on,
the checking interval of automatic failback is
displayed within the parentheses following on.
The time is in minutes.
Intermittent
Error Monitor
• Setting for intermittent error monitoring
on: Enabled
off: Disabled
6-38
Command Reference
