Parameter
and
program
informatio
n to be
displayed
Item Description
When automatic failback is off, intermittent
error monitoring is disabled although
Intermittent Error Monitor will be shown as
on. When the automatic failback function is on,
intermittent error monitoring will be enabled.
• Intermittent error monitoring interval and
number of times that the error needs to occur
When intermittent error monitoring is on, the
specified intermittent error monitoring interval
and number of times that the error needs to
occur are displayed within the parentheses
following on. The format is number-of-times-
error-is-to-occur/monitoring-interval. The time
is in minutes.
Dynamic I/O
Path Control
Setting status of the dynamic I/O path control
function
• Setting status
on: Enabled off: Disabled
• Checking interval
The parentheses following the setting status
shows the checking interval for reviewing
information about the switching of controllers
performed by the storage system. "Minute" is
used as the unit.
If different settings have been specified for each
storage system or LU, an asterisk (*) is added
after the parentheses in which the checking
interval is displayed.
-msrv
Information
about the
HDLM
manager
HDLM Manager
Status of the HDLM manager:
Alive: Normal
Dead: Stopped
Ver
Version number of the HDLM manager
WakeupTime
Startup time of the HDLM manager
-adrv
Information
about the
HDLM alert
driver
HDLM Alert
Driver
Status of the HDLM alert driver:
Alive: Normal
Dead: Stopped
Ver
Version number of the HDLM alert driver
WakeupTime
Startup time of the HDLM alert driver
ElogMem Size
Size of error log memory for the HDLM alert driver in
kilobytes
