Parameter
and
program
informatio
n to be
displayed
Item Description
If the collection of audit log data is disabled, a
hyphen (-) is displayed.
Audit Log
Facility
The name of the audit log facility is displayed. user,
local0, local1, local2, local3, local4, local5,
local6, or local7 is displayed.
If the collection of audit log data is disabled, a
hyphen (-) is displayed.
-
lbpathuse
times
The
number of
times the
same path
can be
used for
load
balancing
Times Same
Path Was Used
The number of times the same path can be used for
I/O operations when the Round Robin (rr), Least
I/Os (lio), or Least Blocks (lbk) algorithm is used
for load balancing.
If you used Global Link Manager to set the number
of times the same path can be used in units of LUs,
an asterisk (*) is added after the value.
-
expathuse
times
The
number of
times the
same path
can be
used for
extended
load
balancing
Times Same
ExPath Was
Used
The number of times the same path can be used for
sequential I/O operations when the extended Round
Robin (exrr), Least I/Os (exlio), or Least Blocks
(exlbk) algorithm is used for load balancing.
If you used Global Link Manager to set the number
of times the same path can be used in units of LUs,
an asterisk (*) is added after the value.
-pstv
The
display-of-
the-
physical-
storage-
system-
information
setting
Physical Storage
View
The value of the display-of-the-physical-storage-
system-information setting is displayed.
on: Enabled
off: Disabled
#
When you use cluster software, the settings of the cluster support
function and the product name of the cluster software is not
displayed. However, the cluster support function will operate
normally.
