When you specify the -path parameter together with the -item
parameter, the command only displays the items specified by the value of
the -item parameter.
If you specify no value for the -item parameter, only the PathID and the
Status fields are displayed.
The following table lists the correspondence between the display items
that can be selected by using the -item parameter and the parameter
values that can be specified after the -item parameter.
Table 6-12 Items That Can Be Selected by the -path -item Parameter and
the Sub-parameters
Selectable items Sub-parameters
PathID
#
None
PathName pn
DskName dn
iLU lu
ChaPort cp
Status
#
None
Type type
IO-Count ic
IO-Errors ie
DNum dnu
HDevName hd
IEP iep
HBAPortWWN hbaportwwn
Physical-LDEV phys
Virtual-LDEV virt
Physical-DskName vid
Physical-iLU vid
Physical-ChaPort vid
Org-DskName ha
Org-iLU ha
#
Because both PathID and Status are always displayed, you do not have
to specify any parameters.
In the sub-parameters following -path -item, you can list the paths (-
hdev) and sort the list (-srt). If you omit both parameters, the command
displays information for all the paths in ascending order of AutoPATH_IDs.
6-46
Command Reference
Hitachi Dynamic Link Manager (for AIX) User Guide
