These sub-parameters are:
-pstv|-vstv
If the -pstv parameter is specified, information about the physical
storage system is displayed. If the -vstv parameter is specified,
information about the storage system recognized by the operating
system is displayed. If neither parameter is specified, information is
displayed according to the value specified in the -pstv parameter of
set operations.
For information about the items that are displayed differently
depending on the specified -pstv and -vstv parameters, see
Table
6-10 Display items for which the display results of the view operation
differ depending on the -pstv parameter specification on page 6-32 in
Parameters on page 6-18.
-hdev host-device-name
Displays information only for the paths accessing the specified host
device.
Specify hdisk name for host-device-name.
The host-device-name string is case sensitive.
When you specify this parameter, HDevName is displayed by default.
Therefore, it is not necessary to specify hd for the -item parameter.
-stname
Use this parameter to display the model ID of the storage system in
the product ID element of the DskName field. When this parameter is
omitted, the command displays the product ID or emulation type of
the storage system instead.
For details about the information displayed for product IDs, see Table
6-15 Product ID Displayed by the View -Path Operation on page
6-56.
When you use this parameter, DskName is displayed by default.
Therefore, it is not necessary to specify dn for the -item parameter.
-srt {pn|lu|cp}
Use this parameter to sort the path information in ascending order,
according to the specified sorting keys.
The sorting keys are as follows: the first sorting key is the name of
the storage system (DskName), the second sorting key is the value
specified by the -srt parameter, and the third sorting key is
AutoPATH_ID.
The available parameter values to specify the second sorting key are:
• pn: Path name
• lu: LU number of the storage system
• cp: Port number of the CHA
When the -srt parameter is omitted, the path information is listed in
ascending order of AutoPATH_IDs.
