When you use the -c parameter, the number of characters that can be
displayed in the product ID element of the DskName field is limited to 10.
When there are 11 or more characters in the product ID, the 8th and
following characters are abbreviated to ellipses (...).
The sub-parameters (following -path -c) are:
-pstv|-vstv
If the -pstv parameter is specified, information about the physical
storage system is displayed. If the -vstv parameter is specified,
information about the storage system recognized by the operating
system is displayed. If neither parameter is specified, information is
displayed according to the value specified in the -pstv parameter of
set operations.
For information about the items that are displayed differently
depending on the specified -pstv and -vstv parameters, see
Table
6-10 Display items for which the display results of the view operation
differ depending on the -pstv parameter specification on page 6-32 in
Parameters on page 6-18.
-stname
Use this parameter to display the model ID of the storage system in
the product ID element of the DskName field. When this parameter is
omitted, the command displays the product ID or emulation type of
the storage system instead.
For details about the information about product IDs, see Table 6-15
Product ID Displayed by the View -Path Operation on page 6-56.
-srt {lu|cp}
Use this parameter to sort the path information in ascending order,
according to the specified sorting key.
The sorting keys are as follows: the first sorting key is the name of
the storage system (DskName), the second sorting key is the value
specified by the -srt parameter, and the third sorting key is
AutoPATH_ID.
The available parameter values to specify the second sorting key are:
• lu: LU number of the storage system
• cp: Port number of the CHA
When the -srt parameter is omitted, the path information is listed in
ascending order of AutoPATH_IDs.
-t
Omits the title for each information item.
Example
The following example shows how to display a summary of the path
information in order of iLUs.
