Displayed Item
Description
No
summary
displayed
Summary
displayed
IO-Count
Total I/O count for all the displayed paths, indicated by a
decimal number. The maximum value that can be displayed is
2
32
- 1 (4294967295). If the total I/O count reaches the
maximum value, it is reset, and the count is re-started from 0.
IO-Errors
Total I/O error count for all the displayed paths, indicated by a
decimal number. The maximum value that can be displayed is
2
32
- 1 (4294967295). If the total I/O error count reaches the
maximum value, it is reset, and the count is re-started from 0.
PathID
The AutoPATH_ID indicated by a decimal number.
The AutoPATH_ID is assigned every time the host is restarted
or when a path configuration is changed. When a new LU was
added and the host has not been restarted, AutoPATH_ID is
assigned to each path of the LU when you execute the cfgmgr
command.
PathName
#
1
-
The path name, which indicates a path. When you modify the
system configuration or replace a hardware item, you should
check the path names to identify the path that will be affected
by the change. Path name consists of the following four
elements, separated by periods:
• HBA adapter number or adapter type (character string)
• Bus number or adapter number (character string)
• Target ID (hexadecimal number)
• Host LU number (hexadecimal number)
For details about each element of the path name and its
representation in AIX, see
Table 6-14 Elements of a Path
Name on page 6-55.
DskName
#1
DskName
Storage system name, which identifies the storage system that
is accessed by a path.
A storage system name consists of the following three
elements, separated by periods:
• Vendor ID: The name of the storage system vendor (for
example, HITACHI).
• Product ID: Indicates the storage system product ID,
emulation type, or model name (for example, OPEN-3).
• Serial number: The serial number of the storage system
(for example, 15001).
You can identify an actual storage system by referencing the
above information from the storage system management
program.
iLU
#1
iLU
LU number of the storage system
This number combined with the storage system name (shown
in DskName) identifies the LU that is accessed by a path.
Command Reference
6-51
Hitachi Dynamic Link Manager (for AIX) User Guide
