Element AIX representation
Corresponding
information
Adapter type (example:
00)
#2
None Always 00
Adapter number (example:
01)
#2
fscsi number (the xx part
of fscsixx)
The fscsi number, which is
displayed by executing the
lsdev -C command
Target ID (example:
00000000000000E2)
Target ID The value of scsi_id, which
is displayed by executing
the lsattr -El hdisk-name
command
Host LU number(example:
0001)
Logical unit ID or LUN The value of lun_id, which
is displayed by executing
the lsattr -El hdisk-name
command
#1
This element is applied when the NPIV option is set to off for the
dlmodmset utility for setting the HDLM execution environment ODM.
#2
This element is applied when the NPIV option is set to on for the
dlmodmset utility for setting the HDLM execution environment ODM.
Table 6-15 Product ID Displayed by the View -Path Operation
Model names of storage
systems
Product ID
Without the -stname
parameter
With the -stname
parameter
(Displays the following
for the model name)
Thunder 9500V series
product identifier
#
9500V
Hitachi AMS2000 series AMS
Hitachi AMS series AMS
Hitachi WMS series WMS
Hitachi SMS series SMS
HUS100 series HUS100
Lightning 9900V series
Emulation type
#
9970/9980
SVS SVS
• Hitachi Universal
Storage Platform 100
• Hitachi Universal
Storage Platform 600
• Hitachi Universal
Storage Platform 1100
USP
6-56
Command Reference
Hitachi Dynamic Link Manager (for AIX) User Guide
