Model names of storage
systems
Product ID
Without the -stname
parameter
With the -stname
parameter
(Displays the following
for the model name)
• Hitachi NSC55
• Hitachi Universal
Storage Platform V
• Hitachi Universal
Storage Platform VM
USP_V
Hitachi Virtual Storage
Platform
VSP
VSP G1000 VSP_G1000
HUS VM HUS_VM
P9500 P9500
XP7 XP7
XP128 XP128
XP1024 XP1024
XP10000 XP10000
XP12000 XP12000
XP20000 XP20000
XP24000 XP24000
#
When a summary is displayed by specifying the -path -c parameter and
there are 11 or more characters in the summary string, any characters
after the 9th character are not displayed,and ellipsis (...) are displayed
instead.
To Display LU Information
When displaying LU information, if the -item parameter, -c parameter, or
the -c -item parameter is specified at the same time as the -lu parameter,
you can add and display items and display a summary of LU information. This
section describes each parameter and the LU information and displayed
items.
To display LU information
-lu
When neither the -c nor -item parameter is specified with the -lu
parameter, the information about the LU recognized by HDLM is displayed
without selecting items to be displayed or displaying a summary. The
Command Reference
6-57
Hitachi Dynamic Link Manager (for AIX) User Guide
